• Model NO.：Hh50z
• Lift height：6m
• Condition：New
• Transport Package：Nude Package, Suitable for Shipment
• Specification：3480*1485*2380MM
• Trademark：HUAHE
• Origin：Zhejiang
• Production Capacity：100units, Month

Power type

Diesel

Rated capacity

kg

5000

Load center

mm

600

Lift height

mm

3000

Free lift height

mm

150

Fork size

N*U*L

mm

1220*150*65

Mast inclination

Front/Back

deg

6/12

Front o-verhang

mm

590

Overall dimensions

Length to face of   fork

mm

3480

Overall width

mm

2000

Mast lowered height

mm

2625

Overhead guard   height

mm

2250

Turning radius

mm

3370

Min. right angle aisle width

mm

3755

Travel speed

km/h

13/12

Lift speed

mm/s

600/400

Max. gradeability

%

20

self weight

kg

8850

Tires

Front

8.25-15-14PR

Rear

8.25-15-14PR

Tread

Front

mm

1470

Rear

mm

1700

Wheelbase

mm

2250

Min. ground (no   ldad/full load)

Mast

mm

174/145

Frame

mm

190/180

Battery

Voltage

V/Ah

2*12/90

Engine

Model

ISUZU

Rated output

KW/RPM

82/2200

Rated torque

N.M/RPM

411/1600

Displacement

CC

6494

No.of cylinder

6

Transmission

Type

Hydraulic

Shift

(Fwd/Rwd)

2/1

Battery

Voltage

V/Ah

12/90

Operating pressure

Mpa

18
