Electric Forklift Truck (3.0-4.5ton)
Jiangsu Gather Power Industry Co., Ltd.- Power：AC Motor
- Load Capacity：1T - 5T
Base Info
- Model NO.：CPD30-45
- Fuel：Electric
- Load center：>500mm
- Lift height：>5000mm
- Condition：New
- Transport Package：Seaworthy
- Specification：small
- Trademark：GP
- Origin：China
- HS Code：8427109000
- Production Capacity：1000PCS,Year
- Package size per unit product：205.60cm * 109.00cm * 199.50cm
- Gross weight per unit product：3120.000kg
Description
General Manufacturer GP 1 Model CPD10 CPD15 2 Rated capacity kg 1000 1500 3 Load center mm 500 4 Power type Battery 5 Tire type Front/Rear Pneumatic 6 Wheels Front/Rear 2*2 Dimensions 7 Lift height mm 3000 8 Free lift height mm 162 9 Fork size L*W*T mm 920*100*40 10 Mast tilt angle Fwd/Bwd deg 6/12 11 Overall length (without fork) mm 2056 12 Overall width mm 1090 13 Mast height fork lowered mm 1995 14 Overall height fork raised mm 4042 15 Overall height (overhead guard) mm 2162 16 Turning radius (outside) mm 1820 17 Load distance (centerline of front axle to front face of forks) mm 429 18 Minimum Aisle -90 degree stack(Add load length and clearance) mm 3370 19 Wheel base mm 1250 20 Tread Front mm 890 21 Rear mm 920 22 Min. Under-clearance Bottom of mast mm 95/110 23 Bottom of frame mm 95/105 Performance 24 Speed Travel Max. With load km/h 11.5 11 25 Without load km/h 13.5 13 26 Lifting With load km/h 300 285 27 Without load km/h 400 390 28 Max. Drawbar pull With/without load Kn 6 6.5 29 Max. Gradeability With/without load % (fan) 15 Weight 30 Service weight kg 2900 3120 Tyre 31 Tyre Size Front 6.5-10-10PR 32 Rear 5.00-8-8PR power control 33 Battery Voltage V 48 34 Capacity AH *400/440/480 35 Electric motor drive motor kw/rpm 5.3/1700 36 lift motor kw 8.2/1600 37 controller GE separate excitation controller 38
