China Teu Diesel Forklift 1.5t 2t 2.5t 3t Diesel Fork Lift Truck
Hefei Thai-Sun Trading Co., Ltd.- Cab Location：Adjustable
- Type：Reach Forklift
- Power：DC Motor
- Load Capacity：1T - 5T
- Fuel：Gasoline
- Load center：500mm
Base Info
- Model NO.：FD15T FD20T FD25T FD30T
- Lift height：3000~5000mm
- Condition：New
- Color：Yellow or as Required
- Max Lifting Weight：3000 Kg
- Tire：Pneumatic Tire or Solid Tire
- Powered：Diesel Engien
- Free Lift：155 mm
- Wheelbase：1425 mm
- Laoding Center：500mm
- Lifting Height：3000mm
- Transport Package：Nuded or as Customer′s Requirement
- Trademark：Thai-Sun
- Origin：China
- HS Code：8427209000
- Production Capacity：2000 Sets,Month
Description
Overview
Product DescriptionDetailed Photos1 Manufacturer THAI-SUN 2 Model Power shift T/M FG15T 3 Load capacity kg 1500 4 Load center mm 500 5 Power unit gasoline/LPG 6 Operator type Driver/seat 7 Tire type Pneumatic 8 Wheel Front/rear 2/2 Dimensions 9 Max. lifting height mm 3000 10 Free lift mm 155 11 Fork size L×W×T mm 920*100*35 12 Tilt range Mast forward/backward deg 6/12 13 Overall length(without fork) mm 2245 14 Total width mm 1070 15 Mast height (fork lowering) mm 1995 16 Overall height fork raised (with backrest) mm 4030 17 Height to head guard mm 2060 18 Turning raduis(outside) mm 2040 19 Front face of fork to front axle mm 395 20 Min. right angle stacking aisle mm 2435 Performance 21 Speed Max Travelling full load/no load km/h 14/14.5 22 Lifting full load/no load mm/s 450/450 23 Lowering full load/no load mm/s 330/520 24 Max.drawbar pull full/no load Kg 1420/690 25 Gradeability at 1.6km/h full/no load % 20/18 weights 26 Truck weight kg 2520 27 Weight
distribution full load front/rear kg 3560/460 28 no load front/rear kg 1090/1430 Chassis&Wheels 29 front wheel 6.50-10-10PR 30 rear wheel 5.00-8-10PR 31 Wheelbase mm 1425 32 Tread front mm 890 rear mm 900 33 Ground
clearence At lowest point(mast) mm 115 Frame mm 105 34 Brake Service brake Hydraulic-foot pedal Parking brake Mechanical-hand lever Drive Line 35 Battery Voltage/capacity 12/60 36 Engine Model NISSAN K21 Rated power kw/rpm 31.2/2250 Rated torque Nm/rpm 144/1600 Number of cylinders 4 Placement L 2.065 37 Fuel tank capacity L 50 38 Transmission Speed forward/backward 1-1 power shift T/M 39 Operating pressure Hydraulic system pressure Kg/cm² 180
distribution
clearence
Our Advantages Exhibition Packaging & Shipping FAQ
1. Are you the TEU forklift dealer?
Yes, we have been TEU forklift dealer for more than 5 years.
2. What is your MOQ for forklift?
The MOQ is 1 set forklift.
3. Do you have the after-sale service?
Yes, TEU has the internationla after sale service.
4. What trade terms do you accept?
FOB, CIF, EXW
