New Diesel Engine Ltmg China 2ton Telescopic Forklift Handler with Good Service
Xiamen LTMG Machinery Co., Ltd.- Cab Location：Not Adjustable
- Type：Diesel Forklift
- Power：Diesel Engine
- Load Capacity：1T - 5T
- Fuel：Diesel
- Load center：500mm
Base Info
- Model NO.：FT30
- Lift height：3000mm
- Condition：New
- Engine：Xinchai Engine 4D27g31
- Fork Size：1070mm*125mm*45mm
- Weight：4500kg
- Wheelbase：1850mm
- Load Centrer：500mm
- Max. Lifting Height：4000mm
- Min. Ground Clearance：190mm
- Height of Closed Cabin：1450mm
- Warranty：1 Year,2000 Working Hours
- Boom Tilting up/Down：60,-2
- Max. Driving Speed：20km,H
- Front Wheel：28X9-15
- Rear Wheel：6.5-10
- Transport Package：Container
- Specification：2900mm*1300mm*2200mm
- Trademark：LTMG
- Origin：China
- HS Code：8427209000
- Production Capacity：1000set,Years
Description
Basic Info.
Model NO. FT30 Lift height 3000mm Condition New Engine Xinchai Engine 4D27g31 Fork Size 1070mm*125mm*45mm Weight 4500kg Wheelbase 1850mm Load Centrer 500mm Max. Lifting Height 4000mm Min. Ground Clearance 190mm Height of Closed Cabin 1450mm Warranty 1 Year/2000 Working Hours Boom Tilting up/Down 60/-2 Max. Driving Speed 20km/H Front Wheel 28X9-15 Rear Wheel 6.5-10 Transport Package Container Specification 2900mm*1300mm*2200mm Trademark LTMG Origin China HS Code 8427209000 Production Capacity 1000set/YearsProduct Description
| Performance | Technical data |
| Rated Capacity ,kg | 3000 |
| Engine | Xinchai engine 4D27G31/Yanmar engine 4TNE98 |
| Total weight,kg | 4500 |
| Max. lifting height,mm | 4000 |
| Wheel base,mm | 1850 |
| Front wheel tread,mm | 990 |
| Rear wheel tread,mm | 990 |
| Min. ground clearance,mm | 190 |
| Total length,mm | 2900 |
| Total width, mm | 1300 |
| Total height,mm | 2200 |
| Height of closed cabin,mm | 1450 |
| Rear-mounted length,mm | 520 |
| Max. horizontal reach,mm | 2090 |
| Boom tilting up/down,(°) | 60°/-2° |
| Max. driving speed,Km/h | 20 |
| Front wheel | 28x9-15 |
| Rear wheel | 6.5-10 |
