• Model NO.：FT30
• Lift height：3000mm
• Condition：New
• Engine：Xinchai Engine 4D27g31
• Fork Size：1070mm*125mm*45mm
• Weight：4500kg
• Wheelbase：1850mm
• Load Centrer：500mm
• Max. Lifting Height：4000mm
• Min. Ground Clearance：190mm
• Height of Closed Cabin：1450mm
• Warranty：1 Year,2000 Working Hours
• Boom Tilting up/Down：60,-2
• Max. Driving Speed：20km,H
• Front Wheel：28X9-15
• Rear Wheel：6.5-10
• Transport Package：Container
• Specification：2900mm*1300mm*2200mm
• Trademark：LTMG
• Origin：China
• HS Code：8427209000
• Production Capacity：1000set,Years

Basic Info.

Model NO. FT30 Lift height 3000mm Condition New Engine Xinchai Engine 4D27g31 Fork Size 1070mm*125mm*45mm Weight 4500kg Wheelbase 1850mm Load Centrer 500mm Max. Lifting Height 4000mm Min. Ground Clearance 190mm Height of Closed Cabin 1450mm Warranty 1 Year/2000 Working Hours Boom Tilting up/Down 60/-2 Max. Driving Speed 20km/H Front Wheel 28X9-15 Rear Wheel 6.5-10 Transport Package Container Specification 2900mm*1300mm*2200mm Trademark LTMG Origin China HS Code 8427209000 Production Capacity 1000set/Years

Product Description

Performance	Technical data
Rated Capacity ,kg	3000
Engine	Xinchai engine 4D27G31/Yanmar engine 4TNE98
Total weight,kg	4500
Max. lifting height,mm	4000
Wheel base,mm	1850
Front wheel tread,mm	990
Rear wheel tread,mm	990
Min. ground clearance,mm	190
Total length,mm	2900
Total width, mm	1300
Total height,mm	2200
Height of closed cabin,mm	1450
Rear-mounted length,mm	520
Max. horizontal reach,mm	2090
Boom tilting up/down,(°)	60°/-2°
Max. driving speed,Km/h	20
Front wheel	28x9-15
Rear wheel	6.5-10
