Lonking 3 Ton Diesel Forklift Cpcd30 Fd30 (T) with Fork Positioner

Maxizm Construction Machinery (Qingdao) Co., Ltd.
  • After-sales Service：Forever
  • Warranty：1 Year
  • Cab Location：Adjustable
  • Type：Diesel Forklift
  • Power：Diesel Engine
  • Load Capacity：1T - 5T

Base Info

  • Model NO.：CPCD30
  • Fuel：Diesel
  • Load center：500mm
  • Lift height：3000~5000mm
  • Condition：New
  • Power Type：Diesel
  • Free Lifting Height：165mm
  • Fork Size：1070*125*45mm
  • Dead Weight：4220kg
  • Max Lifting Speed：485,505mm,S
  • Transport Package：Nude Package
  • Specification：3770*1225*2130 mm
  • Trademark：Lonking
  • Origin：China
  • HS Code：84272090
  • Production Capacity：1000units,Month

Description

MODELCPCD30/FD30(T)PowertypeDieselRatedcapacity(Kg)3000JLoadcentre(mm)500h1STDMaxliftingheight(mm)3000h3Freeliftingheight(mm)165L5*W*TSTDForksize(mm)1070×125×45Masttiltangle(deg)6/12L3Frontoverhang(mm)478L4Rearoverhang(mm)540R1Min.turningradius(mm)2460Min.width for pallets 1,000×1,200 crossways (L×W)(mm)4155Speed(load/unload) Max.travelingspeed(km/h)20Max,liftingspeed(mm/s)(load/unload)485/505Max.gradient(%)20STD Dead weight(kg)4220S/PTread(frnt/rear)(mm)1000/980L2Axledistance(mm)1700Min.groundclearance m2Mast(mm)130m1Frame(mm)160Optinal EngineEngine ModelC490BPG-225QC490GP-159C02-624YN4A055-31CRRated Power(kw/rpm)40/250039/250036.8/250036.8/2600Max.Torque(Nm/rpm)156/1800157/2000157/1800180/1800Number of Cylinders4444Displacement (L)2.672.672.672.67
