4 Wheels Electric Forklift Truck Capacity 2t/ 2.5t/ with Cuitis Controller Ce Certification
Jiangsu Gather Power Industry Co., Ltd.- Power：AC Motor
- Fuel：Electric
- Load center：500mm
- Lift height：3000~5000mm
- Condition：New
- Transport Package：Conventional Packing
Base Info
- Model NO.：CPD20
- Specification：mini electric forklift
- Trademark：GP
- Origin：China
- HS Code：8427209000
- Production Capacity：50000units ,Years
Description
pecification 1 ManufacturerGP GP 2 Model CPD20 CPD25 CPD30 CPD35 3 Power Type Electric 4 Rated Load Capacity kg 2000 2500 3000 3500 5 Load Centre mm 500 Dimensions 6 Rated Lift Height mm 3000 7 Free Lift Height mm 140 145 8 Tilting Angle (F/R, α°/β°) Deg 6°/12° 9 Height when Mast Lowered mm 2045 2060 10 Height to Safeguard mm 2150 2150 11 Min. Ground Clearance mm 120 130 12 Length (to Fork Face) mm 2388 2518 2578 13 Width mm 1150 1225 14 Fork Size (L×W×T) mm 1070×125×40 1070×125×45 15 Fork Spread (Min./Max.) mm 250/1040 250/1100 16 Overhang Front mm 478 483 17 Overhang Rear mm 410 435 495 18 Min. Turning Radius mm 2080 2260 2320 19 Height when Mast Lifted mm 4145 4160 20 Working Aisle Width with Pallet (Ast)*,
1000×1200 Crossways mm 3925 4080 4140 21 Working Aisle Width with Pallet (Ast)*,
800×1200 Lengthways mm 4025 4180 4240 Performance 22 Travel Speed (Full Load) km/h 12 12 23 Travel Speed (No Load) km/h 13 13 24 Lifting Speed (Full Load) mm/s 290 280 25 Lifting Speed (No Load) mm/s 400 400 26 Gradeability (Full Load) % 15 15 12 27 Gradeability (No Load) % 15 15 13 28 Service Brake (Operation/Control) Foot/Powershift 29 Parking Brake (Operation/Control) Hand/Mechanical Drive 30 Tyre (FrontX2) 7.00-12-12PR 28×9-15-12PR 31 Tyre (RearX2) 18×7-8-14PR 18×7-8-14PR 32 Tread (Front) mm 970 1000 33 Tread (Rear) mm 950 970 34 Wheelbase mm 1500 1600 Weight 35 Total Weight (Include Battery Box) kg 4060 4260 5150 5570 36 Front Axle Weight Distribution(Full Load) kg 5180 5823 7210 8070 37 Rear Axle Weight Distribution (Full Load) kg 880 937 940 1000 38 Front Axle Weight Distribution (No Load) kg 1675 1665 2318 2520 39 Rear Axle Weight Distribution (No Load) kg 2385 2595 2832 3050 Drive 40 Drive Motor kw 11 12 41 Pump Motor kw 11 12 42 Standard Battery V/Ah 48/560 80/500 43 Controller Type AC 44 Controller Manufacturer ZAPI 45 Operating Pressure for Attachment Mpa 17.5
- Duplex/duplex full free/triplex mast
- Side shifter/fork positioner/rotator/paper roll clamps
- Removable wide view cabin/air conditioner/heater
- Solid tyre/no-marking solid tyre/super elastic tyre
For more information, please kindly contact us.
Main features:
1000×1200 Crossways
800×1200 Lengthways
- Duplex/duplex full free/triplex mast
- Side shifter/fork positioner/rotator/paper roll clamps
- Removable wide view cabin/air conditioner/heater
- Solid tyre/no-marking solid tyre/super elastic tyre
For more information, please kindly contact us.
Main features:
- Our electic forklift are equipped with Germany Hawker battery and Chinese battery for you to choose from.
- Suspension cab for our forklift truck.
- 300mm small steering wheel for our fork lift.
- Side battery design, change battery in one minute.
- Suspension pedal and hand brake with button.
