• Model NO.：CPQ(Y)D50
• Lift height：3000~5000mm
• Condition：New
• Forklift Size(mm)：1070*150*55
• Reted Capacity：5000kg
• Power Type：Gasoline,LPG
• Mast Tilt Angle(F/R)：6,12(Deg)
• Battery(Voltage/Capacity)：12V,60ah
• Transport Package：Standard Packing
• Specification：2510*1910*2050
• Trademark：GP
• Origin：Shanghai
• Production Capacity：5000 Pieces Per Year

Modle CPQYD50Power type LPGRated Capacitykg5000Load Centremm500Lift Height mm3000Fork sizemm1070*150*55Mast Tile Angle F/RDeg6/12Front Overhangmm470Ground Clearancemm120Length to face of Forkmm2600Overall widthmm1150Mast Lowered Heightmm2055Mast Extended Height(backrest)mm4050Overhead Guard Heightmm2070Turning Radiusmm2310Min.insecting aislemm2380speed travel(Empty)km/h19speed Lifting(full load)mm/s530Max Gradeability%20 front Tire 7-12-12PRRear Tire 6-9-10PRWheelbasemm1600Service weightmm3700BatteryV/Ah12/80Engine Modle K25Manufacture NISSIANEngine Rated output/r.p.mkw37.4/2300Engine Rated torque/r.p.mN.m176.5/1600No.of Cylinder 4Bore. STROKEmm89*100Displacementcc2488Fuel Tank CapacityL60Type HydraulicTransimission stage 1/1Operating Pressure for AttachmentMpa17.5
