• Model NO.：FD30Z
• Lift height：3000~5000mm
• Condition：New
• Lifting Height：3000mm
• Forks Lxwxh：1070X125X45mm
• Min.Turning Radius：2600mm
• Overhead Guard Height：2170mm
• Min.Ground Clearance：120mm
• Max.Traveling Speed(Loaded)：20km,H
• Overall Width：1230mm
• Mast Lowered Height：2065mm
• Wheelbase：1800mm
• Fuel Tank：70L
• Engine Model：QC490gp
• Transport Package：20gp
• Specification：6cbm
• Trademark：ZOOMLION
• Origin：Anhui, China
• HS Code：84279000
• Production Capacity：300PCS,Month

Specifications of professional designed FD30Z 3ton diesel forklift

Features

Power type

-

 Diesel

Rated Load

kg

3500

Load Center

J

mm

500

Lifting Height

h1

mm

3000

Free Lifting Height

h3

mm

145

Fork Size (L*W*T)

mm

1070×125×45

Mast Tilt Radius( Front/Rear)

-

6/12

Minimum turning Radius

R1

mm

2400

Minimum Stacking Right Angle Channel Width

mm

4280

Minimum Right Angle Channel Width

mm

2120

Minimum Ground Clearance

h4

mm

120

Overhead Guard Height

mm

2090

Front Overhang

L3

mm

475

Performance

Max. Travelling Speed Full load





 km/h

20

Max. Lifting Speed Full load

 mm/s

470

Max. Traction Full load

KW

18

Max. Climbing Ability

 %

20

Dimensions

Overall Length Without Fork

L1

mm

2695

Overall Width

W1

mm

1230

Max. Fork Lifting height (With Load Backrest)

 mm

4265

Mast Lowered Height

h2

 mm

 2055

Chassis

Tyre( Front/Rear )

 28x9-15-12PR

6.50-10-10PR

Wheel Base

mm

1700

Wheel Tread Front/Rear

mm

1000/970

Curb Weight Without Load

 Kg

 4350

       Power

Battery Voltage/Capacity

 V/Ah

12/90

Engine Model

 XINCHAIG495BPG

Rated Power

kw/r.p.m

34.5/2500

Rated Torgue

 Nm/r.p.m

139/1800

Bore*Stroke

mm

 95×105

Cylinder Amount

4

Displacement

L

2.36

Fuel Tank Volume

L

70

 Gears front/back

 2/2Manual shift, 1/1Power shift

Work Pressure

MPa

17.5
