• Model NO.：SF20D
• Lift height：>5000mm
• Condition：New
• Model Number：Sf20d
• Rated Loading Capacity：2000kg
• Max. Lifting Height：3515mm
• Min. Lifting Height：390mm
• Fork Length：1520mm
• Fork Width：150mm
• Self Weight (Kg)：7900
• Transport Package：Nude
• Specification：40CBM
• Trademark：MAFAL
• Origin：Shandong
• Production Capacity：5000

ITEMUnitSF20dGeneralLoad capacitykg2000Load centermm500Power typeBatteryDimensionsLift sizemm3000Free lift heightmm155Fork sizemm1070×122×40Mast tilt angledeg6./12 Fork overhangmm462Overall dimensionsFull lengthmm3397Full widthmm1160Height with mast not liftedmm2110Height with mast liftedmm4005Overhead guard heightmm2130Minimum turning radiusmm2050Minimum right angle passage widthmm3912PerformanceDrive speed (full load/no load)Hydraulic forklift truckkm/h12./14Full-load lifting speedmm/sec260Maximum gradeability%10Curb weightkg42000TiresFront wheel7.00-12NHSRear wheel18*7-8NHSWheel & tiresTreadFront wheelmm960Rear wheelmm950Wheelbasemm1500Ground clearance (full load/no load)Mastmm94/110Framemm130/140Drive units & controlApplicable vehicle typeSF20ATmodelXQ-8-7rated power8Current Rating222Rated voltageDC45controlAnhui British Branch INCO





Performance:

Terrain forklift is used at the airport, docks, stations and other poor road conditions for material distribution and it has good maneuverability, reliable ability .

Terrain forklift run faster than ordinary forklift, their mobility is obvious with high engine power and terrain performance .

It apply to the mountains, plateaus pavement, snow jobs, construction sites, mines, orchards pastures, rough roads and mining enterprises .

This product can use Yuchai 4105 engine(supercharge) and Cummins engines, it can meet different customer at home and abroad .



Features:

    1 all- hydraulic steering system , greatly reduce operator fatigue; using transverse cylinder steering mechanism with reliable and compact structure.

  2.  Digitized intelligent traffic monitoring system allows the operator to easily get forklift operation information, make forklift operation to achieve full control .

3.humanization design. using multifunction steering, European-style instruments, and equipped with car cigarette lighter; luxurious seat with seat belts, joystick makes it easy, safe, flexible to operate.

  4. lengthened and widened wheelbase and wheeltrack , get better stability, more suitable for terrain conditions .

  5. air filter with a vacuum alarm, double filtration; external high exhaust muffler, plus a protective shield against hot, ensure security.

1.. Which countries do we export to?
Asia: Vietnam, India, Indonesia, Pakistan, Kazakhstan, Uzbekistan, etc.
Europe: Russia, Belarus, Ukraine, Lithuania, Saudi Arabia, etc.
South America: Brazil, Chile, Paraguay, Argentina, etc.
Africa: South Africa, Ethiopia, Libya, Ghana,Algeria,etc.

2.What are our advantages compared with other manufacturers/factories?
1)Reliable Quality: Carefully select regular manufacturers for supporting spare parts,like engines,bridge,transmissions,and many parts designed and produced by ourselves,
always adapting the best materials.
2)Competitive Price: Concentration of mechanized production in large quantities reduce
production cost to ensure that our price is competitive.
3)Service Team: First, our sales managers are online 24 hours,ready to answer your
questions at any time. Second, professional maintenance team with senior technicians,
ready to provide support services to users and dealers. Most problems can be solved
within 24 hours.
4)Fast Delivery:Under normal circumstances,we can delivery with 10 working days in
factory after receiving pre-payment.
3.Which payment terms can we accept?
Normally we can work on T/T or L/C.
1)On T/T term, 30% payment is required in advance for production, 70% balance shall
be paid before delivery or against the copy of original B/L for old long cooperation clients.
2)On L/C term, 100% irrevocable L/C at sight without "soft clauses" can be accepted.
4. How long is the validity of our quotation?
As a reliable supplier, basically our price remains stable through one year, we only adjust
our price based on two situations:
1)The rate of USD
2)TheThe price of material

Other questions, please contact me directly!!
0086-15921244786  Peter
