• Model NO.：FD45
• Lift height：3000~5000mm
• Condition：New
• Fork Size：1070*150*55
• Weight：7230kg
• Engine：Perkins
• Wheelbase：2000mm
• Color：Decided by Buyer
• Service Brake：Hydraulic
• Rated Power：52kw,2300rpm
• Max. Lifting Height：3000mm
• Warranty：1 Year , 2000 Working Hours
• Max.Gradeability：20%
• Transport Package：Container
• Specification：3245mm*1430mm*2270mm
• Trademark：LTMG
• Origin：China
• HS Code：84272090
• Production Capacity：800sets,Year

Features    1Manufacturer                           LTMG2Model                              FD453Load capacity                         kg45004Load center                            mm6005Power unit                                Diesel   6Operator type                          Driver/seat 7Tire type                             Pnenumatic  8Wheel                                    Front/rear 2/2Dimension  9Max. lifting height                    mm300010Free lift                              mm14011Fork size                            L*W*Tmm1220*150*5012Tilt range                                Mast forward/backward          deg6/1213Overall length(without fork)     mm310014Total width                              mm148515Mast height (fork lowering)   mm230016Overall height fork raised    With backrest                           mm419017Height to head guard               mm227018Turning raduis(outside)           mm278019Front face of fork to front axle mm56020Min. right angle stacking aislepallet size :1100×1100 add clearence                     mm4585Performance   21Speed  Max Travelling          full/no loadkm/h18/1922Lifting                         full/no load    mm/s410/43023Lowering                    full/no load   mm/s380/34024Max.drawbar pull                   full/no load  kg4500/200025Gradeability at 1.6km/h         full load %25Weight            27Truck weight               kg723028Weight  distribution            Full  load               front/rear     kg10780/129029No  load                 front/rear   kg2780/4450Frame           30Tires                                       Number front/rear2/231Model front axle300-15-18PR32rear axle 7.00-12-12PR33Wheelbase                               mm200034Tread                                               Front/rearmm1180/1190 Ground clearence           At lowest point(mast)            mm10035Frame mm240 Brake                                            Service  brake power brake36Parking brake  Mechanical-hand lever                              Engine       37Battery                                          Voltage/capacityV/AH2-12/8038Engine                                          Model  MITSUBISHI S6SRated power kw/rpm52/2300Rated torque N-m/rpm248/1700Number of cylinders  6Displacement L4.99639Fuel tank capacity L8040Transmission                              shift stage(front/rear-type) 2-1 power shift T/M                                         41Operating pressure                    Hydraulic system pressure     kg/cm²200

Product Features

1.Safe:
LED work lights and warning lights make it safer and more efficient evenin poor lighting conditions.
New designed overhead guard protective device prevent the sudden accidents.
Thicker reinforcing plate ensure the safety and efficiency.

2.Easy to operate:
Linde-Technology single chain with reinforced load backrest--makes an excellent and wider field of visionfor operator.

3.Beautiful and comfortable:
New suspension adjustable seat makes the long time operating more comfortable.
Step area is 1.5 times larger with lower step height than fellow forklifts.

4.Durable:
Sunken tilt cylinder under the floor build broader flat floor and less abrasion.
Change plastic slider to alloy copper slider, reduce the abrasion and narrow the gap between masts.
Thicker steering axle bridge deck.

5.Environmental:
Middle muffler, more environmental.

6.High technology:
Maintenance free radiators adopt Germany technology.


After sales service

LTMG always treat after-sale service more important than sale.
Nowadays more than 30 agents around the world can supply LTMG professional after-sale service.
All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please check our website and product certificate.



Shipping & pacakaging


Factory Show




Customer visit
