• Model NO.：CPCD30
• Load Capacity：1T - 5T
• Fuel：Gasoline
• Load center：>500mm
• Lift height：3000~5000mm
• Condition：New
• Fork Size(L*W*T)：1070*140*50mm
• Mast Tilt Angle(Deg)：6,12
• Turning Radius：2200mm
• Self Weight：4000kg
• Battery(V/Ah)：12,100
• Transport Package：Standard Packing
• Specification：2700*1200*2000mm
• Trademark：GP
• Origin：Shanghai
• Production Capacity：5000 Pieces Per Year
• Package size per unit product：270.00cm * 120.00cm * 200.00cm
• Gross weight per unit product：4000.000kg

Modle CPCD30Power type DieselRated Capacitykg3000Load Centremm500Lift Height mm3000Fork sizemm1070*140*50Mast Tile Angle F/RDeg6/12Front Overhangmm470Ground Clearancemm120Length to face of Forkmm2600Overall widthmm1150Mast Lowered Heightmm2055Mast Extended Height(backrest)mm4050Overhead Guard Heightmm2070Turning Radiusmm2310Min.insecting aislemm2380speed travel(Empty)km/h19speed Lifting(full load)mm/s530Max Gradeability%20 front Tire 7-12-12PRRear Tire 6-9-10PRWheelbasemm1600Service weightmm3700BatteryV/Ah12/80Engine Modle K25Manufacture NISSIANEngine Rated output/r.p.mkw37.4/2300Engine Rated torque/r.p.mN.m176.5/1600No.of Cylinder 4Bore. STROKEmm89*100Displacementcc2488Fuel Tank CapacityL60Type HydraulicTransimission stage 1/1Operating Pressure for AttachmentMpa17.5
