• Model NO.：SF50
• Lift height：3000~5000mm
• Condition：New
• Transport Package：Nude Package
• Specification：2597*1150*2702mm
• Trademark：SHANTUI
• Origin：China
• HS Code：8427209000
• Production Capacity：100pieces,Month

Basic Info.

Model NO. SF50 Lift height 3000~5000mm Condition New Transport Package Nude Package Specification 2597*1150*2702mm Trademark SHANTUI Origin China HS Code 8427209000 Production Capacity 100pieces/Month

Product Description

SHANTUI 5 ton mini diesel Forklift SF50 with imported engine and side shift

Description:

Rear Mirror With Wide Angle

Apply the wide angle mirrors in the left and right rear mirrors to widen the rear view, ensuring safe operation.

Built-in Fuel Filler

Built-in fuel  ller and engine hood lock improves the fuel security.

Battery Protection Cover

Ensuring the battery security and protect battery from moisture.





Ergonomic

All Aluminium Radiator

Better cooling performance.

Power Cut-o  Switch Under Engine Hood

Extending the battery life; saving more power when in delivery; protecting switch from moisture and improving safety.





Service Friendly

Enlarged Thermovent

The cooling area is increased by 20%, coolinge ciency is largely improved, engine can be better protected.

Integrated Joints

New 24 degree cone & O-ring integrated joint is accordance with ISO standard, reducing the oil leakage rate by 99%, and extending the lifespan by 3 times.

Parameter:

Model designation		SF50
Power type:Electric-Diesel-Petrol-LPG-Netw ork Power (Electric)	-	Diesel
Operation Type:Hand-stand on-Driver seated	-	Seated
Load Capacity	Q(kg)	5000
Load Barycenter Distance	C(mm)	600
Axle centre to f ork f ace	X(mm)	622
Wheel Base	Y(mm)	2250
Weight
Service Weight	kg	8400
Axle weight with Rated Load f ront/rear	kg	12080/1420
Axle weight without Load f ront/rear	kg	4220/4260
Wheels and tyres
Tyres:SE-Super elastic PN-Pneumatic	-	PN
Front Tyres Size	-	8.25-15-14PR
Rear Tyres Size	-	8.25-15-14PR
Wheels,number front/rear(x=driven wheels)	-
Front Track Width	b10(mm)	1470
Rear Track Width	b11(mm)	1700
Dimensions and Overall Sizes
Mast lif t,f orw ard/backw ard	α/β	6°/12°
Mast Minimum Overall Height	h1(mm)	2500
Free lif t	h2(mm)	205
Lif t height	h3(mm)	3000
Mast Maximum Overall Height	h4(mm)	4429
Overhead Guard Height	h6(mm)	2445
Seat Height	h7(mm)	1395
Drawbar Height	h10(mm)	356
Overall Length	L1(mm)	4737
Length to Face of Forks	L2(mm)	3517
Overall Width	b1(mm)	1995
Fork Arms Dimensions	s/e/L(mm)	55/150/1220
Fork Carriage in Compliance with ISO 2328 Class/Form A,B	-	A
Fork Carriage Width	b3(mm)	1845
Ground Clearance below Mast(with load)	m1(mm)	160
Ground Clearance Centre of Wheelbase(with load)	m2(mm)	190
Aisle Width with pallet 1000×1200 and Fork Arms Pitch 1200	Ast(mm)	5162
Working aisle width with pallet 800 x 1200 lengthways****
Turning Radius	Wa(mm)	3340
Turning Point Minimum Distance from the Truck Center Line	b13(mm)	1095
Performance
Drive Speed with/without load	km/h	27/29
Lif ting Speed with/without load	mm/s	400/560
Low ering Speed with/w ithout load	mm/s	480/380
Draw bar Pull Tractive Ef f ort (at 2km/h) with/without load	KN	53
Gradeability (at 2km/h) with/without load	%	20
Service Brake	-	Mechanical/hydra
Electric engine		--
Engine
Engine Manufacturer/Engine Type	-	Isuzu 6BG1QC-02/WP4.1G125E302
Emission Standard	-
Engine Pow er in compliance with ISO 1585	kw	82.5/92
Rated Number of Revolutions	/min	2000
Cylinder Number/Displacement	cm³	6/6494
Fuel Consumption in Compliance With VDI-Cycl
On-board voltage	V	24
Others
Drive Control Type	-	Electron Hydraulic
Service Pressure f or Attachments	bar	-
Oil Flow rate f or (max.available)	l/min	-
Volume f uel tank	L/kg	140/117
Noise at Operator's Ear	dB(A)	100
Draw bar,model/Type DIN	-	Pin
