Logistic Machinery 2.5 Ton Yto Mini Diesel Forklift Cpcd25 for Sale
Newindu Construction Engineering (Shanghai) Co., Ltd.- Cab Location:Not Adjustable
- Type:Manual Pallet Truck
- Power:Diesel Engine
- Load Capacity:1T - 5T
- Fuel:Diesel
- Load center:500mm
Base Info
- Model NO.:Cpcd25
- Lift height:3000~5000mm
- Condition:New
- Rated Torque:168,1800n.M,R,Min
- Transport Package:Nude Package, Suitable for Shipment
- Trademark:heli
- Origin:Anhui
- Production Capacity:10000units, Year
Description
Model /ModeloUnit/ unidad CPCD20 CPCD25 Power type/ tipo de alimentación Diesel Diesel Rated capacity / La capacidad nominal kg 2000 2500 Load center/ centro de carga mm 500 500 Lift height / altura de elevación mm 3300 3300 Free lift height / Altura de elevación libre mm 120 120 Mast tilt angle (Forward/Backward) / Ángulo de inclinación del mástil (adelante / atrás) Deg 5°/15° 5°/15° Travel speed (with/without load) / Velocidad de desplazamiento (con / sin carga) km/h 18/23 18/23 Max. gradeability (with load) / Max . Pendiente máxima (con carga) % 20/20 17/20 Min. turning radius / Min. radio de giro mm 2900 2940 Fork/ tenedor Length/ longitud mm 1070 1070 Width/ ancho mm 125 125 Thickness / espesor mm 45 45 Overall dimensions ( without forks ) / Dimensiones generales ( sin horquillas) mm 2845×1480×2515 2910×1480×2515 Self.weihgt / Auto . weihgt kg 4500 4750 Engine / motor Model / modelo A495BPG A495BPG Manufacturer / fabricante Xingchang Xingchang Rated output / nominal de salida kw 42/2650 42/2650 Rated torque / par nominal N.m/r/min 168/1800 168/1800 Displacement / desplazamiento L 2.97 2.97
