• Model NO.：EPT20-20RA(S)
• Capacity (Load)：1-10t
• Power Source：Electric
• Max Height：>400mm
• Certification：Ce, SGS
• Size：1140mm*1140mm
• Transport Package：Seaworthy Packages
• Specification：CE, SGS, ISO
• Trademark：SHYTGER
• Origin：Shanghai
• HS Code：84279090
• Production Capacity：5000 Units,Year

 Characteristics1.1Manufacturer HYTGER1.2Model designation EPT20-20RA(S)1.3Drive unit Battery1.4Operator type Ride1.5Load capacityQ (kg)20001.6Load centerc (mm)6001.8Load distance (Raised/ Lowered)x (mm)916/ 982937/ 10031.9Wheelbasey (mm)13801400 Weights2.1Service weight (Incl. battery)kg6702.2Axle loading, laden front/ rearkg1066/ 16042.3Axle loading, unladen front/ rearkg546/  124 Wheels, Chassis3.1Tyre type,operator side/ load side PU/PU3.2Tyre size, operator side 230x753.3Tyre size, load side 2x 85x703.4Balance wheels (dimensions) 130x603.5Wheels, number operator/load side (x=drive wheels) 1x +2/2 or 4 3.6Tread, operator sideb10 (mm)5103.7Tread, load sideb11 (mm)370/ 515 Dimensions4.4Lift heighth3 (mm)1254.9Height of tiller arm in operating position, min/ maxh14 (mm)1150/ 14704.15Fork height, loweredh13 (mm)854.19Overall lengthl1 (mm)186019304.20Length to face of forksl2 (mm)7104.21Overall widthb1/ b2 (mm)7304.22Fork dimensionss/ e/ l (mm)55x170x115055x170x12204.25Fork spread, min/ maxb5 (mm)540/ 6854.32Ground clearance, center of wheelbasem2 (mm)504.33Aisle width, 1000×1200 pallet crosswaysAst (mm)19844.34Aisle width, 800×1200 pallet lengthwaysAst (mm)21844.35Outer turning radiusWa (mm)17001725 Performance5.1Travel speed, laden/ unladenkm/ h7.5 /8.55.2Lifting speed, laden/ unladenm/ s0.056/ 0.0605.3Lowering speed, laden/ unladenm/ s0.057/ 0.0575.8Maximum gradeability, laden/ unladen S2 5 min.%8/165.10Service brake Electromagnetic Drive6.1Drive motor rating S2 60 min.kW1.56.2Lift motor rating at S3 15%kW2.26.4Battery voltage/ rated capacity (5h)V/ Ah24/ 2106.5Battery weight (with box)kg190 Others8.1Type of drive control  AC  ZAPI8.4Sound level at operator's eardB (A)74
