Top Quality Heavy Forklift for Sale
Newindu Construction Engineering (Shanghai) Co., Ltd.- After-sales Service：Video Technical Support, Online Support
- Warranty：1 Year
- Cab Location：Adjustable
- Type：Electric Forklift
- Power：AC Motor
- Load Capacity：5T - 10T
Base Info
- Model NO.：CPCD70
- Fuel：Electric
- Load center：>500mm
- Lift height：3000~5000mm
- Condition：New
- Minimum Ground Clearance：200mm
- Minimum Turning Radius：3370mm
- Gradeability：30%
- Travel Speed：20km,H
- Transport Package：Nude
- Specification：4365*3510*1995mm
- Trademark：NEWINDU
- Origin：China
- Production Capacity：1000units,Per Year
Description
Overview
Product DescriptionModel CPCD70 Power type Diesel Load capacity kg 7000 Load center mm 600 Pallet fork maximum height (with block shelf) mm 4400 Maximum lifting height mm 3000 Free hoisting height mm 200 Overall height (upper frame protection) mm 2450 Full length (with cargo fork) mm 4840 Full width mm 2045 The minimum ground clearance (the door) mm 200 The minimum turning radius (outer) mm 3370 Least square channel width mm 3330 Pallet fork a*b*c mm 1220*150*65 Maximum speed (full/empty) km/h 24/29 Maximum traction(full/empty) KN 62 Maximum gradeability (full/empty) % 32/19 Rated power KW/rpm 83/2000 Rated torque Nm/rpm 450/1400-1500 Total water (oil) kg 9650
Detailed PhotosProduct Parameters
