• Model NO.：CPQYD25
• Fuel：Electric
• Load center：500mm
• Lift height：3000~5000mm
• Condition：New
• Free Lift Height：170mm
• Wheel Base：1600mm
• Min. Ground Clearance：110mm
• Min. Turning Radius：2240mm
• Gradeability：20%
• Transport Package：Nude
• Specification：4365*3510*1995mm
• Trademark：NEWINDU
• Origin：China
• Production Capacity：1000units,Per Year

Detailed PhotosProduct Parameters

Power type

Gasoline

Rated capacity

kg

2500

Load center

mm

500

Operator type

Drive in seat

Max. lift height of mast with Load-backrest

mm

4030

Max.lift  height of fork(standard)

mm

3000

Height of mast (standard)

mm

2000

Free lift height(standard)

mm

170

Height of Load-backrest

mm

995

Distance from seat to overhead guard

mm

1000

Front wheel overhead

mm

2070

Length with fork

mm

3646/2576

Front overhang

mm

477

Rear overhang

mm

494

Wheel base

mm

1600

The height of traction pin

mm

290

Min. ground clearance

mm

110

Overall width

mm

1170

The distance between forks

mm

1024/200

Tread(front /rear)

mm

970/970

Min. Turning radius(outside)

mm

2240

Min. Turning radius(inside)

mm

160

Min. Intersecting aisle

mm

2280

Mast tilt angle

deg

6° / 12°

Fork size

mm

1070X100X45
