- Model NO.:CPCD60
- Condition:New
- Brand Name:Yto
- Rated Capacity:6000kg
- Transmission:Hydraulic Transmission
- Thickness×width×length:60×150×1220
- Overall Length(Without Forks):3510
- Transport Package:Nude Package
- Specification:CE, ISO
- Trademark:YTO
- Origin:China, Henan
- HS Code:84279000
- Production Capacity:1000
Speciality parameter | Model | | | CPCD60 |
|
Power type | | | Diesel |
Rated capacity | | kg | 6000 |
Load center | d | mm | 600 |
Lift height | h2 | mm | 3000 |
Mast tilt angle (forward/backward) | α/β | Deg | 6/12 |
Front overhang | L3 | mm | 590 |
Wheel-base | L4 | mm | 2250 |
Tread(front/rear) | b4/b5 | mm | 1470/1700 |
Performance parameter | Travel brake | | | Hydraulic-Foot pedal |
Parking brake | | | Mechanical-Hand level |
Lift speed(with/without load) | | mm/s | 350/380 |
Lower speed (with/without load) | | mm/s | |
Travel speed (with/without load) | | km/h | 20/21 |
Max. gradeability (with load) | | % | 20 |
Max. Towing (with/without load) | | kN | 42/32 |
Weight Distribution with load(pront/rear) | | | 12940/1630 |
Weight Distribution without load(pront/rear) | | | 3840/4370 |
Power, transmission and others | Engine | Model | | | LR4B3-24 |
Manufacturer | | | YTO |
Rated power | | kw | 64/2400 |
Max.roration | | | 288/1700 |
Dispilacement | | | 4.578 |
Battery | Voltage | | V | 24 |
Capacity | | Ah | 2×100 |
Gearbox | Transmission type | | | Hydraulic |
Gears,speed (front/rear) | | | II/II |
Tire | type | | | |
Model | Pront | | | 8.25-15-14PR |
Rear | | | 8.25-15-14PR |
Other | Self.weight | | kg | 8570 |
Free lift height | h4 | mm | 195 |
Fork | Thickness×Width×Length | c×b×a | mm | 60×150×1220 |
Overall dimensions | Overall length(without forks) | L2 | mm | 3510 |
Overall width | b1 | mm | 1995 |
Overall height | Extended height(mast) | h1 | mm | 4365 |
Lower height(mast) | h3 | mm | 2500 |
Overhead guard | h7 | mm | 2470 |
Min. turning radius | Wa | mm | 3300 |
Min. under ground clearance | Under mast | m1 | mm | 195 |
Center of wheel-base | m2 | mm | 200 |
