Feature | | | Model | | HC15-20 |
1.1 | Q | capacity | kg | 2000 |
1.2 | C | load center | mm | 600 |
1.3 | | operator type | | walkie |
1.4 | | Electric power steering(EPS) | | standard equipped |
|
Dimensions | 2.1 | H1 | lifting height | mm | 120 |
2.11 | H | Max. fork lifting height | mm | 205 |
2.12 | H2 | Lowered height of fork | mm | 85 |
2.13 | H5 | Height of tiller arm in drive position min./max. | mm | 980/1391 |
2.14 | H4 | rear body height | mm | 874 |
2.2 | B1 | standard fork width | mm | 540/685 |
2.3 | L | fork length | mm | 1150/1200 |
2.4 | S | fork thickness | mm | 55 |
2.5 | E | fork width | mm | 185 |
2.6 | L1 | overall length | mm | 1750 |
2.7 | L2 | rear length | mm | 600 |
2.8 | B | overall width | mm | 720 |
2.9 | Wa | minimum turning radius | mm | 1575 |
2.91 | Ast | aisle width (800*1200mm pallet): horizontal/vertical | mm | 1900 |
2.92 | Ast | aisle width (1000*1200mm pallet): horizontal/vertical | mm | 1940 |
|
Performance | 3.1 | | maximum traveling speed | laden | km/h | 4 |
unladen | km/h | 4 |
3.2 | | maximum lifting speed | laden | m/s | 0.056 |
unladen | m/s | 0.06 |
3.3 | | maximum lowering speed | laden | m/s | 0.057 |
unladen | m/s | 0.059 |
3.4 | | gradeability | laden | % | 5 |
unladen | % | 7 |
|
Weight | 4.1 | | Service weight without battery | kg | 422 |
4.2 | | Service weight with battery | kg | 612 |
|
Wheel | 5.1 | | wheel(drive/load) Type | | PU |
5.2 | | wheel quantity(drive/load) | | 1D+4L+1B |
5.3 | D1 | size of steering wheel | mm | ¢248*75 |
5.4 | D2 | size of Loading wheel | mm | ¢80*120(sing wheel)/ ¢80*80(double wheel) |
5.5 | | size of balance wheel | mm | ¢115*55 |
5.6 | Y | wheel base | mm | 1390 |
|
Driving system | 6.1 | | traveling motor | kw | 1.5 AC |
6.2 | | lifting motor | kw | 2.0 DC |
6.3 | | voltage | V | 24 |
6.4 | | battery capacity/type | Ah | 210Ah/industry |
6.5 | | maximum battery box size(L*W*H) | mm | 650*200*535 |
6.6 | | traveling brake | | Regenerate |
6.7 | | brake type | | Electromagnetic |
6.8 | | control system | | CURTIS 1230/200A |
| | | | | | |
Right reserved for technical changes and improvements. |
