2t Narrow Aisle Forklift for Side Loading Forklift

Shanghai Hytger Industry & Trade Co., Ltd.
  • Type：Powered Pallet Truck
  • Power：AC Motor
  • Load Capacity：1T - 5T
  • Name：2t Narrow Aisle Forklift for Side Loading Forklift
  • Transport Package：Standard Exporting Packing
  • Specification：CE, SGS, ISO

Base Info

  • Model NO.：CCD-2C
  • Trademark：SHYTGER
  • Origin：Shanghai, China
  • HS Code：84272090
  • Production Capacity：3000units,Year

Description

ModelCCD-2CCarrying capacity (load centre 0.6m)2000kgMax.lift weight6mFork free lift height0.3mMax.lift speed0.25m/sMax.traveling speed15km/hFork tilt anger (front/rear)5°/3°Min.turning radius4.3mGradeability (laden)15%Min.ground clearance (laden)0.17m
Overall
dimensionLength4.45m Width2.03m HeightFork in the lowest position2.7m  Fork in the highest position4.66mWheel base2.46mTruck width1.6mPlatform height (laden)0.92mPlatform width1.15mFork length1.15mMax.fork spacing0.94mTyres size8.25-15-14PRWeight (unladen)6800kgVolts AH battery80V/700AhTraction motor16.6kwPump motor13.5kwControl systemA-Impulse(CURTIS)
