• Model NO.：CPCY28
• Fuel：Diesel
• Load center：500mm
• Lift height：3000~5000mm
• Condition：New
• Approved：FDA
• Dedicated Chain Type：Sprocket
• Structure (for Chain)：Plate Chain
• Material Feature：Heat Resistant
• Usage：Transmission Chain, Transpor
• Color：White.Blue.Gray.Brown
• Transport Package：3 Units in One Hq40 Container
• Specification：CCC, ISO, SGS
• Trademark：Haiqin
• Origin：Shandong, China
• HS Code：84295100
• Production Capacity：8000 Units , Year

Main Technical Parameters of CPCY28ItemParameterNoteRated load (KG)2800 Load center (mm)565 Lifting height (mm)3000 Free lift height (mm)150 Mast tilt angle front/rear (°)6/12 Max lifting speed (full load) (mm/s)372 Running speed (km/h)Advance:I gear/II gear8/16 Backlash:I gear/II gear8/16 Max climbing gradient (%) (full load)50 Max traction (Kgf)2587 Max steering angle (°)±35 Swinging angle of rear axle (°)±12 Min turning radius (mm)4500 External dimensionsLength (mm)4585ToothWidth (mm)1700 Height (mm)2720 Min ground clearance (mm)260 Dead weight (Kg)3268

2, Certificate of Haiqin Machinery:




3, Warranty and Service.

HAIQIN Forklift has One Year Warranty.
During Warranty, if there is any part broken because of quality problem(except easy-damaged parts), send us detailed pictures and video, then we will send good/ new parts for your replacements.

Choose HAIQIN, and then better after-service will be guaranteed.

Contact us right now for more information!  Online 24 hours a day!
