• Model NO.：SH100
• Condition：New
• Load Capacity (T)：10t
• Power Type：Diesel
• Lifting Height：3000mm
• Free Lift：195mm
• Fork Width：175mm
• Fork Thickness：80mm
• Backrest Height：1015mm
• Load Center (mm)：600
• Max. Lifting Speeds ( with Load ) mm/S：310
• Gradeability (with/Without Load ) %：19,20
• Transport Package：Container, FCL,LCL
• Specification：CE
• Trademark：sinoheng
• Origin：Shandong
• Production Capacity：300PCS,Month

Product Name10Ton Counterbalance Diesel Forklift TruckModelSH100Load capacity (kg)10000Load center (mm)600Power typeDieselMax. lifting speeds ( with load )  mm/s310Max. driving speeds ( with/without load )  km/h16/22Max. towing ( with/without load )  kn57Gradeability (with/without load )  %19/20Lifting height (mm)3000Free lift (mm)195Tilting angles ( forward-backward )  (  .)6/12Min. turning radius (mm)3900Min. right angle aisel width ( mm )3540Min. under-clearance (mm)250
DimensionOverall length (including fork)mm5480Overall width ( mm )2275Overall height (mast lowered )mm2850Overall height (mast extend )mm4297Overall height to overhead guard (mm)2585Fork overhang (mm)718Wheel base (mm)2500TreadFront tread (mm)1600Rear tread (mm)1700TyreFront tyre9.00-20-14Rear tyre9.00-20-14Total weight (kg)12510Fork width (mm)175Fork thickness (mm)80Backrest height (mm)1015Fork length (mm)1220

EngineEngine modelChaochai6102-BGRate power (KW)80.9Rotate speed at Rate power (rpm)2500Max. torque  (nm)353Rotate speed at max torque (rpm)1650Battery2-12 V/80AHType of power shiftTor-non
