• Model NO.：HH30Z
• Fuel：Electric
• Load center：>500mm
• Lift height：3000~5000mm
• Condition：New
• Certification：CE, ISO
• Fork Width：125mm
• Fork Length：1070mm
• Power Souce：Diesel Engine
• Weight：4280kg
• Mast Lowered Height：2070mm
• Turning Radius：2400mm
• Transport Package：Nude Packing
• Specification：3760*2090*1225 mm
• Trademark：HUAHE
• Origin：Hefei, China
• HS Code：84272090
• Production Capacity：500sets,Month

Overview Product DescriptionProduct ParametersSpecification1Model HH30Z-N2-D2Rated capacitykg30003Load centermm5004Lift heightmm30005Fork sizeL×W×Tmm1070×125×456Mast inclinationfront/back(α°/β°)Deg6/12Size7Overall DimensionLength(to fork face)mm26808Overall Widthmm12259Mast lowered heightmm209510Height When Mast Liftingmm418011Safeguard Heightmm212012Turning Radius minmm246013Front Overhangmm49014Treadfront/backmm1000/97015Ground Clearance min(no load/full load) mast/framemm152/132158/13816Wheelbasemm170017Fork Spreadmin/maxmm300/1200Performance18SpeedTravel (Laden)km/h20/18.519Lifting (Laden)mm/s48020Grade abilityLaden%2021Service Weight(include battery )kg440022TireFront 28×9-15-12PR23rear 6.50-10-10PRDiesel Engine24XINCHAI 490BPGRated OutputKw/rpm37/265025Rated TorqueN.m/rpm148/180026Displacementcc254027No.of Cylinder 428Bore*Strokemm90*10029Operating Pressure for AttachmentMpa17.5Detailed Photos
