2.5ton Heli Brand Logistic Truck Cpcd25 Diesel Forklift
Cruking Engineering Equipment (Xiamen) Co., Ltd.- After-sales Service：Free Accessories Are Provided During The Warranty
- Warranty：1 Year
- Cab Location：Not Adjustable
- Type：Diesel Forklift
- Power：Diesel Engine
- Load Capacity：1T - 5T
Base Info
- Model NO.：CPCD25
- Fuel：Diesel
- Load center：500mm
- Lift height：3000~5000mm
- Condition：New
- Free Lift Height：155 mm
- Tilting Angles(Forward/Backward)：6,12 Deg
- Max. Travelling Speeds(Loaded/Unloaded)：17,19 Km,H
- Lifting Speeds(Loaded/Unloaded)：550,600 mm,S
- Max Negotiable Gradient(Loaded/Unloaded)：25,18 %
- Min. Outside Turning Radius：2240 mm
- Min. Inside Turning Radius：160 mm
- Fork Dimensions：1070*122*40 mm
- Min. Ground Clearance Under Mast：110 mm
- Wheel Base：1600 mm
- Internal Combustion Engine Rated Output：34.1,2400 Kw,Rpm
- Internal Combustion Engine Rated Torque：155.9,1600 Nm,Rpm
- Displacement：2.434 L
- Fuel Tank Capacity：66 L
- Transport Package：Nude Package
- Specification：3650*1150*2140 mm
- Trademark：HELI
- Origin：China
- HS Code：84295100
- Production Capacity：100,Month
Description
Overview
Product Description
Detailed PhotosProduct ParametersCompany Profile
