Ltmg 2ton Diesel Forklift with Optional Triplex Full-Free Mast

Xiamen LTMG Machinery Co., Ltd.
  • Cab Location：Adjustable
  • Type：Powered Pallet Truck
  • Power：Diesel Engine
  • Load Capacity：2t
  • Fuel：Diesel
  • Load center：500mm

Base Info

  • Model NO.：FD20
  • Lift height：3000~5000mm
  • Condition：New
  • Item：Forklift Machines
  • Engine：Mitsubishi or Other
  • Fork Size：1070mm*122mm*40mm
  • Max. Lifting Height：3000mm
  • Weight：3330kg
  • Wheelbase：1600mm
  • Overall Length(Without Fork)：2460mm
  • Truck Weight：3330kg
  • No. of Cylinders：4
  • Free Lift：160mm
  • Transport Package：Container
  • Specification：2460mm*1150mm*2120mm
  • Trademark：LTMG
  • Origin：China
  • HS Code：84272090
  • Production Capacity：500sets,Year

Description

Speed Max Travelling full/no loadkm/h17/19Lifting  full/no loadmm/s550/580Lowering  full/no loadmm/s450/550Max.drawbar pull Power shift T/M full/no loadkg1670/830Manual shift T/M full/no loadkg1700/830Gradeability at 1.6km/hPower shift T/M full/no load%27/20Manual shift T/M full/no load  %21/20Truck weight kg3330Weight  distributionFull load  front/rearkg4700/630No  load front/rear                                 kg1510/1820Tires Numberfront/rear2/2Modelfront axle 7.00-12-12PRrear axle6.00-9-10PRWheelbase mm1600Tread Front/rearmm970/970Ground clearanceAt lowest point(mast)mm110Framemm115BrakeService  brake Hydraulic-foot pedal  Parking brake Mechanical-hand leverBatteryVoltage/capacityV/AH12/80EngineModel Mitsubishi S4SRated powerkw/rpm35.4/2250Rated torqueN.m/rpm170/1700Number of cylinders 4PlacementL2.369Fuel tank capacityL70TransmissionSpeed forward/backwardPower shift T/M
Manual shift T/M 1-1 power shift T/M
2-2 manual shift T/MOperating pressureHydraulic system pressurekg/cm²180

Product Features

1.Safe:
LED work lights and warning lights make it safer and more efficient evenin poor lighting conditions.
New designed overhead guard protective device prevent the sudden accidents.
Thicker reinforcing plate ensure the safety and efficiency.

2.Easy to operate:
Linde-Technology single chain with reinforced load backrest--makes an excellent and wider field of visionfor operator.

3.Beautiful and comfortable:
New suspension adjustable seat makes the long time operating more comfortable.
Step area is 1.5 times larger with lower step height than fellow forklifts.

4.Durable:
Sunken tilt cylinder under the floor build broader flat floor and less abrasion.
Change plastic slider to alloy copper slider, reduce the abrasion and narrow the gap between masts.
Thicker steering axle bridge deck.

5.Environmental:
Middle muffler, more environmental.

6.High technology:
Maintenance free radiators adopt Germany technology.


Packing & Delivering

Ltmg 2ton Diesel Forklift with Optional Triplex Full-Free Mast




Our Factory
Ltmg 2ton Diesel Forklift with Optional Triplex Full-Free Mast


Customers
Ltmg 2ton Diesel Forklift with Optional Triplex Full-Free Mast



After-sale service

LTMG always treat after-sale service as important as sale. Nowadays more than 50 agents around the world can supply LTMG professional after-sale service.

All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.

Detail clauses and policies please check our website and product certificate.


Ltmg 2ton Diesel Forklift with Optional Triplex Full-Free Mast
Ltmg 2ton Diesel Forklift with Optional Triplex Full-Free Mast




FAQ

1. What Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate.  Some of our products meets the EPA requirements.
LTMG never recruit Underage labor.

2. Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.

3. How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

5. What payment terms do you accept?
Normally 30% T/T in advance as deposit, balance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.

6. Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is 30 days.
