Ltmg Forklift Truck 5ton Diesel Forklift for Sale

Xiamen LTMG Machinery Co., Ltd.
  • Warranty：1 Year , 2000 Working Hours
  • Cab Location：Adjustable
  • Type：Diesel Forklift
  • Power：Diesel Engine
  • Load Capacity：5 Ton
  • Fuel：Diesel

Base Info

  • Model NO.：FD50
  • Load center：>500mm
  • Lift height：3000~5000mm
  • Condition：New
  • Fork Size：1070*150*55mm,1220*150*70mm
  • Weight：6980kg,9750kg
  • Engine：Chinese Engine,Isuzu,Mitsubishi
  • Wheelbase：2100mm,2250mm
  • Color：Could Be Designed by Buyer
  • Free Lift：205mm
  • Tire Type：Pneumatic
  • Optional：Solid Tires, Side Shift, Three Stage Mast, etc
  • Height to Head Guard：2265mm,2470mm
  • Transport Package：Container
  • Specification：3245*1430*2270mm,3560*2010*2500mm
  • Trademark：LTMG
  • Origin：China
  • HS Code：84272090
  • Production Capacity：1000 Units,Year

Description

ManufacturerModelLoad capacityLoad centerPower unitOperator typeTire typeWheelMax. lifting heightFree liftFork size L*W*TTilt rangeOverall length(without fork)Total widthMast height (fork lowering)Overall height fork raisedHeight to head guard mmTurning raduis(outside) mmFront face of fork to front axle mmMin. right angle stacking aisle mmSpeedTruck weight kg8150WeightTires Number front/rear2/2Tires Modelfront axleWheelbase mm20002250TreadGround clearenceServiceParking brakeEngine ModelISUZU 6bg1Rated power kw/rpm82.3/2000Rated torque N.m/rpm416/1400-1600Number of cylinders6Placement L6.4946.494Fuel tank capacity L140140Hydraulic system pressure kg/cm²200200
Product Features



1. Equipped with Chinese powerful and reliable engines with excellent environmental performance; Original imported Isuzu, Mitsubishi and Cummins engines are optional.



2. Work lights and warning lights make it safer and more efficient even in poor lighting conditions



3. New designed overhead guard protective device prevent the sudden accidents: The lifting system adopts buffering technology to reduce shock and vibration of the mast.



4.high strength-solder bath mast. Wide filed of the front vision ensures the safety of the operation and improves work efficiency.

Exhibition & customer
Ltmg Forklift Truck 5ton Diesel Forklift for Sale
Ltmg Forklift Truck 5ton Diesel Forklift for Sale

Packaging & Shipping
Ltmg Forklift Truck 5ton Diesel Forklift for Sale


Our company:
Ltmg Forklift Truck 5ton Diesel Forklift for Sale
Ltmg Forklift Truck 5ton Diesel Forklift for Sale


After sales service

Nowadays we have been sell more than 100 countries. All the products of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
If the machine have any problem within the warranty time, but not caused by man-made, we will send you spare parts for free.

Detail clauses and policies please see to our website and product's quality certificate.
