• Model NO.：FG25
• Lift height：3000mm
• Condition：New
• Turning Radius(Outside)：2240mm
• Weight：3580kg
• Engine Model：Chinese Engine,Japanese Engine
• Number of Cylinders：4
• Warranty：1 Year or 2000 Hours
• Color：Customize
• Fuel Tank：70L
• Operator Type：Driver,Seat
• Tire Type：Pneumatic
• Fork Size：1070mm*122mm*40mm
• Mast Type：Duplex or Triplex Mast
• Optional：Fork Positioner, Full Free Mast, Cab etc.
• Transport Package：Container
• Specification：2530mm*1150mm*2120mm
• Trademark：LTMG
• Origin：China
• HS Code：8427209000
• Production Capacity：800sets,Month

Features   Manufacturer     LTMGModel   Power shift T/M        FG25Load capacity kg2500Load center mm500Power unit   Gasoline/LPGOperator type  Driver/seat Tire type Front/rear PnenumaticWheel Front/rear 2/2Dimension Max. lifting height mm3000Free lift  mm160Fork size L*W*Tmm1070*122*40Tilt rangeMast forward/backwarddeg6/12Overall length(without fork)  mm2530Total width mm1150Mast height (fork lowering) mm1995Overall height fork raisedWith backrest mm4030Height to head guard mm2120Turning raduis(outside)  mm2240Front face of fork to front axle mm450Min. right angle stacking aislewithout load length&clearence                    mm2690PerformanceSpeedMax Travelling                 full/no loadkm/h17/19Lifting full/no load mm/s550/580Lowering full/no load mm/s450/550Max.drawbar pullPower shift T/M full/no load    kg1650/830Gradeability at 1.6km/hPower shift T/M  full/no load   %22/18Weight           Truck weight  kg3580Weight   distributionFull load  front/rearkg5370/710No   load  front/rear kg1390/2190Frame          Tires                                       Numberfront/rear2/2Modelfront axle 7.00-12-12PRrear axle6.00-9-10PRWheelbase                              mm1600Tread                                                Front/rearmm970/970Ground clearence                 At lowest point(mast)       mm110Framemm115Brake                                           Service brake Hydraulic-foot pedal  Parking brake Mechanical-hand lever   Engine       Battery                                         Voltage/capacityV/AH12/60Engine    Model Nissan K21Rated powerPS(kw/rpm)47/2250(34.6/2250)Rated torquekg-m   max.(N.m)15.7/1600(153/1600)Number of cylinders 4PlacementL2.065Fuel tank capacityL70TransmissionSpeed forward/backward Power shift T/M                        1-1 power shift T/MOperating pressureHydraulic system pressure kg/cm²180
Product Features



1.The standard LED lamps and warning lights make it safer,more energy efficient and create better werking condition.
2.Equipped with imported gas system which is more reliable.
3.Thicker reinforcing plate ensures the safety and efficiency.
4.New designed overhead guard protective device prevent the sudden accidents.
5. Original Toyota seat with safety belt
6. Japanese engine7.LPG cylinder diameter is optional.Packing & Delivery



Our factory


Our customer



After-sale service

LTMG always treat after-sale service important as the same as product quality.
LTMG grants our clients a twelve-month-period or 2000-hours warranty for any machine purchased from us.
LTMG can also help clients coordinate with trained service personnel to provide you detailed and extensive knowledge about your specific machine. With our technical advises, your machine service life can be significantly prolonged and sustained with high capacity.
