Forklift Clamp 2500lbs 3000lbs 3500lbs 5000lbs Forklift Truck 3 Ton Forklift with Paper Roll Clamp

Xiamen LTMG Machinery Co., Ltd.
  • Warranty：1 Year,2000 Working Hours
  • Cab Location：Not Adjustable
  • Type：Diesel Forklift
  • Power：Diesel Engine
  • Load Capacity：1T - 5T
  • Fuel：Diesel

Base Info

  • Model NO.：FD30
  • Load center：500mm
  • Lift height：3000mm
  • Condition：New
  • Engine：Isuzu C240
  • Fork Size：1070mm*125mm*45mm
  • Weight：4300kg
  • Wheelbase：1700mm
  • Load Centrer：500mm
  • Ground Clearence：120mm
  • Color：Decided by Buyer
  • Fuel Tank：70L
  • Optional：Side Shift Mast Height, Mast Stage, etc
  • Transport Package：Container
  • Specification：2660mm*1225mm*2115mm
  • Trademark：LTMG
  • Origin：China
  • HS Code：8427209000
  • Production Capacity：1000set,Years

Description

SpeedMax Travelling full/no loadKm/h 18/19.5Lifting full/no loadmm/s 450/500Lowering full/no loadmm/s 450/450Max. Drawbar pullFull/no loadKg 1550/1000Gradeability at 1.6km/hFull load% 25Truck weight  Kg 4290Weight distributionFull load front/rearKg 6420/870No load front/rearKg 1680/2610TiresNumberFront/rear 2/2ModelFront axle 28X9-15-12PRRear axle 6.50-10-10PRWheelbase  mm 1700TreadFront/rearmm 1000/970Ground clearenceAt lowest point(mast)mm 120Framemm 135BrakeService brake   Hydraulic-foot pedaParking brake   Mechanical-hand leverBatteryVoltage/capacityV/AH 12/80EngineModel   ISUZU C240Rated powerKw/rpm 52/2500Rated torqueN-m/rpm 15.7/1800Number of cylinders   4Fuel tank capacity  L 70TransmissionShift stage(front/rear-type)   1-1 power shift T/MOperating pressureHydraulic system pressureKg/cm² 180
