High Quality Used 10ton Fd100 Japanese Diesel Forklift Truck

Sinomada Heavy Industry (Changsha) Co., Ltd.
  • Cab Location：Adjustable
  • Type：Diesel Forklift
  • Power：Diesel Engine
  • Load Capacity：5T - 10T
  • Fuel：Diesel
  • Load center：500mm

Base Info

  • Model NO.：Fd100
  • Lift height：3000~5000mm
  • Condition：New
  • Working Pressure：20 MPa
  • Transport Package：Container,Roro,Bulk
  • Specification：4245x2245x2640mm
  • Trademark：Zoomlion
  • Origin：China
  • HS Code：8427209000
  • Production Capacity：500unit,Month

Description

Specifications  unitFD100CharacteristicsPower dieselRated Capacitykg10000Center of loadmm600Lifting heightmm3000Free lifting heightmm220Forks L×W×Hmm1220×175×80Tilt Forward/Backward.6/12Min.turning radiusmm3900Min.ground clearance(Mast)mm250Overhead guard heightmm2600Height from seat to overhead guardmm1090Front overhangmm715PerfMax.traveling speed(loaded)km/h26Max.lifting speed(loaded/empty)mm/s290/350Drawbar pull/GradeabilitykN/%57/20DimensionsOverall length (without fork)mm4260Overall widthmm2230Mast lowered height mm2850Mast extended heightmm4335ChassisTireFront 9.00-20-14PRRear 9.00-20-14PRWheelbasemm2800Tread widthFront/Rearmm1600/1700Curb weightNone-loadkg12500PowertrainBatteryVoltage/CapacityV/Ah(12/90)x2EngineModel XC6110Rated powerkw/r.p.m83/2000Rated torqueNm/r.p.m450/1450Cylinder amount 6Bore×Stroke mm110×125Displacement 7.127Fuel tankL140Transmission 1/1 automatic transmissionWorking pressureMPa20
