• Lift height：3000~5000mm
• Condition：New
• Capacity：1500kg,2000kg
• Drive Unit：Electric
• Overall Length：2060mm
• Overall Width：850mm
• Overall Height：1485-2485mm
• Max Working Height：1600-4500mm
• Free Lift Height：2900mm
• Lowered Fork Height：90mm
• Fork Dimensions：1150*160*56mm
• Max. Fork Width：850mm
• Turning Radius：1675mm
• Drive Motor Power：1.5kw AC
• Lift Motor Power：3.0kw
• Battery：210ah,24V
• Net Weight：1345kg
• Transport Package：1PCS,Pallet
• Specification：Capacity: 1500kg
• Trademark：CE
• Origin：Jiangsu, China (Mainland)
• HS Code：8427900000
• Production Capacity：300 Pieces , Month

Basic Info.

Lift height 3000~5000mm Condition New Capacity 1500kg/2000kg Drive Unit Electric Overall Length 2060mm Overall Width 850mm Overall Height 1485-2485mm Max Working Height 1600-4500mm Free Lift Height 2900mm Lowered Fork Height 90mm Fork Dimensions 1150*160*56mm Max. Fork Width 850mm Turning Radius 1675mm Drive Motor Power 1.5kw AC Lift Motor Power 3.0kw Battery 210ah/24V Net Weight 1345kg Transport Package 1PCS/Pallet Specification Capacity: 1500kg Trademark CE Origin Jiangsu, China (Mainland) HS Code 8427900000 Production Capacity 300 Pieces / Month

Product Description

Main Characters

1. Top quality AC controller system from CURTIS, high reliability, ensures best performance in different states.
WINNER hydraulic power pack, low noise, few vibration and excellent leak tightness, ensures smooth lifting.

2. AC traveling motor, maintenance-free, provides stronger power and climbing capability.

3. High-strength frame design and 3-layer "H" shaped mast, strong and durable, ensures longer service life.

4. Folded pedal, with buffering function, avoid shake while traveling.

5. Humanized design of handrail, protect the operator when operating.

6. Vertical motor designing, ensures inspection and maintenance of motor and brake system conveniently.

7. Configure with 210Ah large capacity battery, intelligent charger, REMA plug from Germany.

8. EPS electric power steering system, light and nimble operation.


Model		CDD15E	CDD20E
Capacity	kg	1500	2000
Lifting Height	mm	1600/2000/2500/3000/3500/4000/ 4000S/4500S	1600/2000/2500/3000/3500/4000/ 4000S/4500S
Overall Height Mast Closed	mm	2010/1485/1735/1985/2235/2485/ 1820/1990	2010/1485/1735/1985/2235/2485/ 1820/1990
Overall Length	mm	2010/2060	2050/2100
Overall Width	mm	850	850
Turning Radius	mm	1675	1720
Min.intersecting Aisle	mm	2325	2370

FAQ:

Q: What about the quality of the products?
A: Our products are CE approved, and we have five inspection steps before shipment:
1. Inspect the raw material in accordance with ISO9001;
2. Strict inspection in the whole production process;
3. Load limit test when assembling finished;
4. 100% strict inspection of products before shipment;
5. If needed, inspection by buyer.

Q: How long is the quality guarantee?
A: All of our products carry one-year warranty.

Q: What's the leadtime?
A: Normally 30 days.
If you order more than 5 itmes mixed in one container, it will be 45 days.
If you order one item in one container, it will be 20 days.
