2020 New CE ISO Certification 3 Stage 3.5 Ton Forklift High Efficiency Diesel Forklift

Xiamen LTMG Machinery Co., Ltd.

Warranty：1 Year,2000 Working Hours
Cab Location：Not Adjustable
Type：Diesel Forklift
Power：Diesel Engine
Load Capacity：1T - 5T
Fuel：Diesel

Base Info

Model NO.：FD35
Load center：500mm
Lift height：3000~5000mm
Condition：New
Engine：Xinchai C495,Isuzu 4jg2PE-01
Fork Size：1070125*50mm
Service Weight：4500kg
Wheelbase：1700mm
Ground Clearence：140mm
Color：Decided by Buyer
Optional：Side Shift, Mast Height, Mast Stage, etc
Transport Package：Container
Specification：2775mm*1225mm*2115mm
Trademark：LTMG
Origin：China
HS Code：8427209000
Production Capacity：1000set,Years

Description

SpeedMax Travelling full/no loadKm/h15.8/20Lifting full/no loadmm/s450/500Lowering full/no loadmm/s450/450Max. Drawbar pullFull/no loadKg1550/1000Gradeability at 1.6km/hFull load%25Truck weight Kg4500Weight distributionFull load front/rearKg6420/870No load front/rearKg1680/2610TiresNumberFront/rear2/2ModelFront axle28X9-15-12PRRear axle6.50-10-10PRWheelbase mm1700TreadFront/rearmm1000/970Ground clearenceAt lowest point(mast)mm120Framemm135BrakeService brake Hydraulic-foot pedaParking brake Mechanical-hand leverBatteryVoltage/capacityV/AH12/80EngineModel Xinchai C495Rated powerKw/rpm42/2650Rated torqueN-m/rpm174/1800-2000Number of cylinders 4Fuel tank capacity L60TransmissionShift stage(front/rear-type) 1-1 power shift T/MOperating pressureHydraulic system pressureKg/cm²180
