Fd35t European Standard Forklift Custom Order
Xiamen Hifoune Technology Co., Ltd.- After-sales Service：Online Service or Local Service
- Warranty：1year,2000h
- Cab Location：Adjustable
- Type：Diesel Forklift
- Power：Diesel Engine
- Load Capacity：1T - 5T
Base Info
- Model NO.：FD35T
- Fuel：Diesel
- Load center：500mm
- Lift height：>5000mm
- Condition：New
- Engine：Xinchai,Isuz,Mitsubish
- Weight：4780kg
- Rated Capacity：3500kg
- Fork Size：1220X125X50mm
- Transmission Box Type：Automatic Transmission
- Tire Type：Pneumatic Tire
- Transmission：Hydraulic
- Optional：Attachment, Side Shifter, Sealed Cab, Mast, etc
- Mast：Duplex Mast (Triplex Mast Optional)
- Color：Customized
- Certification：CE,ISO
- Transport Package：Container
- Specification：2760x1240x2130mm(LXWXH)
- Trademark：Hifoune
- Origin：Cn
- HS Code：8427109000
- Production Capacity：4500sets,Year
Description
FD35TSpecifications Power Unit Diesel Operator Type Driver/seat Transimission Box Type Electronic hydraulic transmisson Rated Capacity kg 3500 Load Center mm 500 Max.Lifting Height mm 3000 Tire Type Pneumatic Tyre Tire Number Front 2 Rear 2 Tire Size Front 28×9-15-14PR Rear 6.5-10-10PR Performance Lifting Speed Loaded mm/s 500 Unloaded 550 Lowering Speed Loaded mm/s 480 Unloaded 450 Travelling Speed Loaded km/h 19 Unloaded 20 Max.Gradeability (Loaded) % 21 Max.Drawbar Pull (Loaded) kg 18 Mast Tilting Angle (Fwd/Bwd) deg 6/12 Free Lifting Height mm 150 Turning Radius mm 2460 Dimensions Overall Length (with fork) mm 2760 Overall Width mm 1240 Overhead Guard Height mm 2130 Fork Size (LxWxT) mm 1220×125×50 Mast Height (Fork lowered) mm 2140 Battery (Voltage/Capacity) V/Ah 12/90 Truck Weight kg 4780 Fuel Tank Capacity L 70 Engine Brand XINCHAI MITSUBISH ISUZ Model C495 S4S 4JG2 Rated Power kw/rpm 42/2650 35.3/2250 44.8/2450 Rated torque n-m/rpm 174/1600 169/1700 186/1800 Number Of Cylinder 4 4 4 Displacement 2.8 2.49 3
Shipping & Packing
About us
Xiamen Hifoune Machinery Co., Ltd. is located in the Xiangan industrial zone of Xiamen torch high tech Zone. It is dedicated to providing reliable and efficient material handling equipment and solutions for customers. It is a professional company integrating R & D, manufacturing, sales and service. Our main products include a full range of internal combustion counterbalanced forklift trucks, electric counterbalance forklift trucks, and electric warehouse equipment. We not only aim to provide excellent products to customers in our full range of products, but also provide excellent service to customers in all links
