Ltmg 1.5 Ton 2ton Electric Pallet Stacker with 3m Lifting Height

XIAMEN LTMG CO., LTD.
  • After-sales Service：Provide
  • Warranty：Provide
  • Cab Location：Not Adjustable
  • Type：Powered Pallet Truck
  • Power：DC Motor
  • Load Capacity：1T - 5T

Base Info

  • Model NO.：ERB15
  • Fuel：Electric
  • Load center：>500mm
  • Lift height：3000~5000mm
  • Condition：New
  • Fork Size：1150mm180mm*60mm
  • Item：Stacker
  • Max. Lifting Height：3000mm
  • Controller：Curtis
  • Max.Lifting Height：3000mm
  • Overall Length：1940mm,2360mm
  • Battery Capacity：24ah
  • Transport Package：Container
  • Specification：1940mm*850mm*2000mm
  • Trademark：LTMG
  • Origin：China
  • HS Code：8428109000
  • Production Capacity：1000sets,Year

Description

Model ERB15ERB18Type Wide legsWheelsWheel type PUPUWheel quantity driving wheel/Balance wheel/Bearing wheel 1/2/41/2/4DemensionStandard lift heightmm30003000Lowered fork heightmm5555Fork size(length/width/thickness)mm1070(920/1150/1200)/100/401070(920/1150/1200)/100/40Overall lengthmm1940/23601970/2390Overall widthmm1170/1320/1470/16501170/1320/1470/1650Outside with between legsmm1170/1320/1470/16501170/1320/1470/1650Inside with between legsmm970/1120/1270/1450970/1120/1270/1450Min.turning radiusmm1565/19751565/1975Min.aisle width for pallets 800×1200mm2230/25602230/2560Min.aisle width for pallets 1000×1200mm2260/25852260/2585Min.groud clearancemm5050PerformanceTravel speed,laden/unladenkm/h5/65/5.8Lift speed,laden/unladenmm/s95/13080/120Travel speed,laden/unladenmm/s110/10080/90Gradeability,laden/unladen%5/85/8Electric configurationDrive motor /Lift motor/Steering motorkwAC1.5/DC3.0/DC0.15AC1.5/DC3.0/DC0.15Battery voltageV2424Battery capacityAh280280Brake Electromagnetic/RegenerativeElectromagnetic/RegenerativeController CURTISCURTISWeightBattery weightkg235235Service weight with batterykg12801370
Product Features
 1.Germany system technology of warehousing equipment and leading international level.
2. The product with the principle of human engineering, fully humanized design.

3. The equipment using the German imports of seal, bearing and electrical components,further to ensure the reliability of the vehicle.

4. Using USA or Italy electronic assembly control, the German import control handle and Italy Metalrota driving wheel,and fully guarantee the stability of vehicle.

5. With strict accordance of ISO9000 and CE standards for product development and production,ensure product quality.

6. Flexible and convenient operation, energy saving and environmental protection, vehicle low noise,stable operation, high safety coefficient.

7. Large capacity of traction battery for vehicles, and fully guarantee the continuous working time.

8. All sold products enjoy a high quality after sale service, ensure the spare parts supply timely,authenticity and continuity, to solve customer any worry from the later period.
Ltmg 1.5 Ton 2ton Electric Pallet Stacker with 3m Lifting HeightLtmg 1.5 Ton 2ton Electric Pallet Stacker with 3m Lifting HeightLtmg 1.5 Ton 2ton Electric Pallet Stacker with 3m Lifting HeightLtmg 1.5 Ton 2ton Electric Pallet Stacker with 3m Lifting Height

FAQ

1.What Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate.  Some of our products meets the EPA requirements.
LTMG neverrecruit Underage labor.

2. Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.

3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

5. What payment terms do you accept?
Normally 30% T/T in advance as deposit, blance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.

6.Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is 30 days.
