• Model NO.：ERDF25
• Fuel：Electric
• Load center：500mm
• Lift height：3000~5000mm
• Condition：New
• Fork Width：122mm
• Overall Dimensions：3605mm*1160mm*2095mm
• Service Weight：3600kg
• Warranty：1 Year
• Max. Driving Speed (with/Without Load)：17,19km,H
• Power Souce：Diesel Engine
• Rated Capacity：2500kg
• Min. Lifting Height：2095mm
• Warranty of Core Components：1 Year
• Certification：CE
• Free Lifting Height：60mm
• Video Outgoing-Inspection：Provided
• Power Type：Diesel
• Lifting Height：3000mm
• Trademark：Everun
• Origin：Shandong, China
• Package size per unit product：380.00cm * 115.00cm * 216.00cm
• Gross weight per unit product：2500.000kg

Specifications1.0 General   (1) Model:

ERDF25

  (2)Rated capacity:2500kg  (3)Load center:500mm

  (4)Power type:

Diesel

 (5) Transmission:

Auto Transmission2.0 Dimensions   (1)Lifting height:

3000mm

  (2)Free lifting height:

60mm

  (3)Turning radius:

2450mm

  (4)Overall length:

3605mm

  (5)Overall width:

1160mm

  (6)Fork length:

1220mm

  (7)Fork width:

122mm

  (8)Fork thickness: 40mm3.0 Performance   (1) Max. driving speed :

       (with/without load)

17/19 km/h

  (2) Max. lifting speed:

         (with load)

400mm/s

  (3) Max. traction :

       (with/without load)

10/15kn

  (4) Gradeability :

       (with/without load)

15/20%

  (5) Tilting angles :

       (forward/backward)

6/12°

  (6)Service weight:

3600kg

4.0 Engine

(1)Power

 36.8kw(2)Rated speed 2500rpm(3)Displacement 2.67L(4)No. of cylinder 45.0 Wheel (1)Front overhang 451mm(2)Wheel base 1640mm(3)Front tread 970mm(4)Rear tread 970mm(5)Front tire 7.00-12(6)Rear tire 6.00-9Company ProfileServiceCUSTOMER'S GOOD PRAIOur AdvantagePackaging

FAQ

Q: What is your payment term?
A: L/C, or T/T 30% down payment, balance to be paid against BL copy and loading pictures.



Q: What is your delivery time?
A: Within 35-35days after receving the down payment.



Q: What is your main market?

A: Europe, North America, South America, Oceania, Southeast Asia, Africa, Eastern Asia and so on.



Q: If products have some quality problem, how would you deal with?
A: We have one year or 1200 working hour warranty for EVERUN wheel loadr, and gurantee you can receive the spare parts within 5 working days. In order to make good service for our European customers, we have set up a warehouse for spare parts in Germany, which could guarantee European customer a better after-service.
