• Model NO.：FG35
• Load center：500mm
• Lift height：3000~5000mm
• Condition：New
• Weight：4500kg
• Engine：Nissan
• Fork Positioner Function：Standard Equipped
• Color：Customized
• Mast：Duplex Mast (Triplex Mast Optional)
• Optional：Side Shifter, Sealed Cab, High Mast, etc
• Certification：CE,ISO
• Transmission：Hydraulic
• Packing &Shipping：Two Units (for 3 Ton ) Fixed Container
• Turning Radius：2480
• Transport Package：Nude Packing, Container
• Specification：2775*1225*2115mm
• Trademark：LTMG
• Origin：China
• HS Code：8427209000
• Production Capacity：300sets,Month

Manufacturer  LTMGModel Power shift T/MFG35Manual shift T/MFG35Load capacity kg3500Load center mm500Power unit  GasolineOperator type  Driver/seatTire typeFront/rear PneumaticWheelFront/rear 2/2Max. lifting height mm3000Free lift mm150Fork sizeL*W*Tmm1070*125*50Tilt rangeMast forward/backwarddeg6/12Overall length(without fork) mm2720Total width mm1285Mast height (fork lowering) mm2075Overall height fork raisedWith backrestmm4250Height to head guard mm2140Turning radius(outside) mm2460Front face of fork to front axle mm485Min. right angle stacking aisle  without load length&clearancemm2940SpeedMax Travelling full/no loadkm/h18/19.5Lifting full/no loadmm/s450/500Lowering full/no load mm/s450/420Max.drawbar pullPower shift T/M full/no loadkg1800/1000Manual shift T/M full/no loadkg1900/1000Gradeability at 1.6km/hPower shift T/M full/no load%17/20Manual shift T/M full/no load%17/20Truck weight kg4610Weight  distributionFull load front/rearkg7260/850No load front/rearkg1840/2770TiresNumberfront/rear2/2Modelfront axle28x9-15-12PRrear axle6.50-10-10PRWheelbase mm1700TreadFront/rearmm1060/970Ground clearanceAt lowest point(mast)mm120Framemm135BrakeService  brake Hydraulic-foot pedalParking brake Mechanical-hand leverBatteryVoltage/capacityV/AH12/60EngineModel Nissan K25Rated powerPS(kw/rpm)51/2300(37.4/2300)Rated torquekg-m    max.(N.m)18/1600(177/1600)Number of cylinders 4PlacementL2.488Fuel tank capacityL70TransmissionSpeed forward/backwardPower shift T/M Manual shift T/M1-1 power shift T/M 2-2 power shift T/MOperating pressureHydraulic system pressurekg/cm²180

FAQ

1.What Certificate do you have?

LTMG workshop meet with the ISO9001:2008 Quality System. All of our products with CE certificate. Some of our products meets the EPA requirements.

2.Can you customize and design as the clients' requirement?

LTMG will try its best to meet all kinds of clients' special requirements. However, All the customizing and refit should be implemented safely and scientifically. The colors can be painted as client's need.

3.How long is the warranty of your products?

Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

4.Can you produce the products labeled with the client's brand?

With the authorization of the brand, we can OEM for our clients.

5.What payment terms do you accept?

On T/T term 30% down payment is required in advance,and 70% balance shall be settled before shipment

6.What logistics waysd we can work for shipment ?

We can ship construction machinery by various transportation tools.

1.For 90% of our shipment,we will go by sea,to all main continents such as South America,Middle East,Africa,Oceania and Europe etc,either by container or Bulk shipment.

2.For neighborhood countries of China,such as Russia,Mongolia, Kazakhstan,Uzbekistan etc., we can ship trucks by railway.

3.For light spare parts in urgent demand,we can ship it by international courier service,such as DHL,TNT,UPS,or Fedex.

7.Delivery time:

Standard configuration products are always in stock. The production period of Customizing products is 30 days.



Welcome to contact us for further questions!
