• Model NO.：Fd35
• Lift height：3000~5000mm
• Condition：New
• Transport Package：Nude Package, Suitable for Shipment
• Specification：3775*1225*2100mm
• Trademark：LONKING
• Origin：Fujian, China
• Production Capacity：1000units, Month

Main ParametersUnitModel No.   FD35(T)1Power Type-Diesel2Rated Capacitykg35003Load Centremm5004Lift Heightmm30005Fork Size(L×W×T)mm1070×125×456Mast Tilt Angle(F/R)deg6°/12°7Front Overhang(wheel center to fork face)mm4788Rear Overhang(wheel center to fork face)mm5809Overall DimensionOverall Length (with fork)mm3830Overall Widthmm1225Mast Lowered Heightmm2077Overhead Guard Heightmm210010Turning Radius(outside)mm252011Min.Intersecting Aislemm421512SpeedMax.Driving Speed(load/unload)km/h20/20Max.Lifting Speed(load/unload)mm/s420/38013Max.Gradeability%2014Service Weightkg475015TireFrontmm28×9-15-14PRRearmm6.5-10-10PR16Wheel Basemm170017Ground Clearance(Bottom Of Mast)mm13218EngineModel-C490BPGMamufacture-XINCHAIRated Outputkw40Rated Torquenm@min-1160/1800-1900No. Of Cylinder-4Displacementcm32.67Fuel Tank Capacityltr60
