• Model NO.：FD100
• Fuel：Diesel
• Load center：600mm
• Lift height：3m
• Condition：New
• Tire：Double Front Pneumatic Tires
• Weight：12450kg
• Engine：Japanese Mitsubishi (Chinese Engine Optional)
• Wheelbase：2800mm
• Fork Positioner Function：Standard Equipped
• Color：Customized
• Max.Lifting Height：3000mm
• Item：10 Ton Diesel Forklift
• Optional：Side Shifter, Sealed Cab, High Mast, etc
• Certification：CE,ISO
• Transport Package：Nude Packing, Container
• Specification：4255*2245*2850mm
• Trademark：LTMG
• Origin：China
• HS Code：8427209000
• Production Capacity：250sets,Month

Features    1Manufacturer                           LTMG2Model                               FD1003Load capacity                         kg100004Load center                            mm6005Power unit                                Diesel   6Operator type                          Driver/seat  7Tire type                           Pneumatic  8Wheel                                    Front/rear 4/2Dimension  9Max. lifting height                    mm300010Free lift                              mm20511Fork size                           L*W*Tmm1220*175*7512Tilt range                                Mast forward/backward          deg6/1213Overall length(without fork)     mm425514Total width                              mm224515Mast height (fork lowering)   mm254816Overall height fork raised     With backrest                           mm433017Height to head guard               mm256018Turning raduis(outside)           mm390019Front face of fork to front axle mm71020Min. right angle stacking aislepallet size :1100×1100 add clearence                    mm6250Performance   21Speed Max Travelling                     full/no loadkm/h24/3022Lifting                                    full/no load    mm/s390/41023Lowering                               full/no load     mm/s470/34024Max.drawbar pull                   full/no load  kg5850/320025Gradeability at 1.6km/h         full load %22 Max. Gradeability full/no load %24/20Weight            26Truck weight                        kg1245027Weight  distribution            Full  load                                 front/rear     kg20160/229028No  load                                   front/rear  kg5480/6970Frame           29Tires                                       Number front/rear4/230Model front axle  9.00x20-14PR31rear axle9.00x20-14PR32Wheelbase                               mm280033Tread                                               Front/rearmm1600/170034Ground clearence               At lowest point(mast)         mm245Framemm32035Brake                                            Service  brake power brake Parking brake  Mechanical-hand lever                                 Engine       36Battery                                          Voltage/capacityV/AH2x12V-80AH37Engine                                          Model  6BG1Rated power kw/rpm82.3/2000Rated torque N-m/rpm418/1500Number of cylinders  6Displacement L6.494Fuel tank capacity L14038Transmission                              shift stage(front/rear-type) 2-2 automatic                                       39Operating pressure                    Hydraulic system pressure    kg/cm²200
