• Model NO.：AL925
• Lift height：4000mm
• Condition：New
• Engine model：Cummins 4BTA3.9 C100
• Rated power：74kw
• Self-weight：63000kg
• Min. ground clearance：260mm
• Transport Package：1 Unit in 20gp Container
• Specification：5560× 2000× 3800mm
• Trademark：ACTIVE
• Origin：Shandong China
• HS Code：8429510000
• Production Capacity：500pieces,Year

Basic Info.

Model NO. AL925 Lift height 4000mm Condition New Engine model Cummins 4BTA3.9 C100 Rated power 74kw Self-weight 63000kg Min. ground clearance 260mm Transport Package 1 Unit in 20gp Container Specification 5560× 2000× 3800mm Trademark ACTIVE Origin Shandong China HS Code 8429510000 Production Capacity 500pieces/Year

Product Description

1,Features:
     It adopts articulated frame, hydraulic-mechanical transmission, lower-pressure, wide-base tyre and four wheel driving, owning good adhesive property, great drawbar force, and excellent cross-country ability.
The working part adopts special channel steel. Equipped with holding apparatus, it is suitable for straw piling and loading job on farms.

Specifications:

Item	Specifications	Item	Specifications
Rated weight	2500kg	Engine model	4BTA3.9-C100
Center of load	550mm	Rated power	74kw
Operating weight	6300kg	Transmission system	Hydraulic-mechanical type
Max. lift height	4000mm	Highest speed	25km/h
Min. ground clearance	260mm	Driving axle	Front-rear engineering axle
Wheel base	1590mm	Turning angle	35°
Tread	2350mm	Tyre	16/70-20
Overall dimensions (l×w×h)mm	5560×2000×3800	Steering system	Load sensing, prior steering
		Service brake	Air over oil disc brake on 4 wheels

3,Delivery period: 20-30 days.
4,Validity of offer: 30 days
5,Packing: 1 piece disassembled, naked within 1 x 20GP container.
6, Guarantee: 12 months.
Details:

Our Customers:

Shipping and delivery:
