• Lift height：3000
• Condition：New
• Product Name：China Brand High Quality Double Lift Electric Pall
• Loading Capacity：1200 Kgs
• Model：Es12
• Power Souce：Electric
• Operate Type：Walkie
• Load Center Distance：600mm
• Wheel Base：1441mm
• Lifting Height：540mm
• Turning Radius：1615mm
• Brand：Jeakue
• Transport Package：Standard
• Specification：1200 Kgs load capacity
• Trademark：Jeakue
• Origin：China
• HS Code：8427102000
• Production Capacity：5000 Set,Year

Basic Info.

Lift height 3000 Condition New Product Name China Brand High Quality Double Lift Electric Pall Loading Capacity 1200 Kgs Model Es12 Power Souce Electric Operate Type Walkie Load Center Distance 600mm Wheel Base 1441mm Lifting Height 540mm Turning Radius 1615mm Brand Jeakue Transport Package Standard Specification 1200 Kgs load capacity Trademark Jeakue Origin China HS Code 8427102000 Production Capacity 5000 Set/Year

Product Description

1.2 T Mast Reach Full Electric Stacker

High intensity body designed, it's suitable for high strength working, and service life of it is long.
Front and back frames contact by connecting rod, which reduces the oscillation in the process of the vehicles on the road
Frame structure is sturdy and durable, which ensures the pallet fork carrying heavy cargo easily.
Using latest electronic steering handle could effectively reduce the working strength and improves the stability and comfort of driving, it effectively relieves much of strength steering needs.
1.Product Details :

Selling point:
Fork can be reach and backward for multi-row shelves.

Performance
1. The innovative AC system offers strong power, accurate control, excellent performance.
2. High strength vertical gearbox, longer working life.
3. Low-noise but durable hydraulic unit, good quality cylinder as well as hose ensure the high realiability of hydraulic system.
4. AMP connecter electric wires and cables, greatly reducing electric parts failure rate.

Safety
1. Safe hydraulic system design prevents mast from falling down abruptly when hydraulic pipeline cuts off.
2. Emergency reverse belly button protects the operator from getting hurt.
3. Emergency dis connector will cut off power source and avoid accident when trucks goes out of control.
4. Multiple lifting limit protection ensures safety.
5. Automatic switch to lower speed when the fork reaches its setting height
6. Anti-rolling back brake keeps the truck from skidding down when truck is out of control or traveling on ramp.

Operation
1. With the new design of ergonomical tiller head, all buttons are controlled conveniently & comfortably.
2. Dual pallets lifting doubles working efficiency.
3. Creep speed function: when handle in near vertical position, the driving speed will decrease aromatically, allowing delicate operation in confined space.
4. Long tiller decreases the operation force greatly and makes operations much easier.
5. Bias Operation, Greater View.

Maintenance
1. AC traction motor, maintenance free.
2. Hour meter and battery indicator remind the operator of battery charging.
3. Easily remove the back cover by only loosing four bolts; Access to all key components for inspection, maintenance and replacement.
4. Easy access for battery maintenance.
5. Vertical motor makes the inspection & service much more convenient.
6. Mast and chassis are assembled together, easy for maintenance.
7. Low voltage cut off setting protects batteries.
