• Model NO.：Cpyd25
• Lift height：>5000mm
• Condition：New
• Transport Package：Nude Package, Suitable for Shipment
• Trademark：YTO
• Origin：Henan, China
• Production Capacity：1000units, Month

Basic Info.

Model NO. Cpyd25 Lift height >5000mm Condition New Transport Package Nude Package, Suitable for Shipment Trademark YTO Origin Henan, China Production Capacity 1000units/ Month

Product Description

China Top Brand Yto 2.5ton Gasoline Forklift Cpyd25

1. Model cpyd25
2. Rated capacity kg 2500
Base data 3. Load centre mm 500
Performance data 4. Lifting height mm b 3000
5. Max. Height(forkcarrage) mm a 4300
6. Mast height mm c 2065
7. Free lift height mm e 300
8. Mast inclination(f/r 0 y 6/12
9. Fork length mm j 1070x120x40
10. Suspension(f/r) mm u 495/475
Unloaded 11. Brakingdistance m f 6
Loaded 12. Lifting speed mm/s k 430
Unloaded 13. Lifting speed mm/s m 450
Loaded 14. Lowering speed mm/s 550
Unloaded 15. Lowering speed mm/s 300
Loaded 16 traveling speed mm/s 18
Unloaded. 17. Traveling speed mm/s 20
18. Min. Turningradius(outsid mm w 2230
19. Min. Turning radius(inside) mm v 155
20. Min. Width of angleaisle mm x 1930
21. Max. Gradient % 15/18
Loaded 22. Axleload front kg 5527
Loaded 23. Axleload rear kg 683
Unloaded 24. Axleload front kg 1670
Unloaded 25. Axleload rear kg 2040
Discluding fork 26. Overall length mm h 2545

27. Overall width mm q 1150
Overhead guard 28. Overall height mm p 2075
Size and weight 29. Wheel mm l 1600
30. Track front mm s 970
31. Track rear mm t 970
32. Min. Ground clearance mm g 110
33. Height of tract pin mm n 245
34. Height from seat to overhead guard mm o 960
35. Spacing(out-to-out) mm r 300-1040
36. Service weights kg 3710
Engine 37. Model A490bpg
38. Power type diesel
Transmission 39. Gear shift(f) 1-1power shift
40. Gear shift(r)) 2-2 hand shift
Braking type 41. Driving brake hydraulic pedal
42. Parking brake mechanical hand
Tyre 43. Front tyre (pneumatic) 28x9-15-12pr
Rear tyre (pneumatic) 6.50-10-10pr
44. Pressure mpa 0.7
Battery 45. Voltage v 12
46. Capacity ah n70
47. Transmission type hydraulic.
The imported engine with original packing has strong power, and can meet the requirements of high-efficient work.
- Precise matching design with advanced energy conservation control can reduce the oil consumption of the machine.
- Low emission meets the Europe II standard.
- The adoption of new cooling fan and large-scale silencer lowers the noise of the machine.
- The adoption of the advanced turbocharging technique increases the highland adaptability of the machine.
- Automatic preheating system improves the working capacity in the low temperature.
- Unique fan cover with the shape of hopper opening greatly improves the air supply of the engine and the radiating capacity of the system, guaranteeing the successive high-efficient work of the machine.
- Restart prevention system effectively avoids the misoperation, and improve the use security of the machine.
