• Model NO.：FD70T
• Load center：600mm
• Lift height：>5000mm
• Condition：New
• Engine：Chaocai,Isuzu
• Weight：9200kg
• Rated Capacity：7000kg
• Fork Size：1220X150X65mm
• Transmission Box Type：Automatic Transmission
• Tire Type：Pneumatic Tire
• Transmission：Hydraulic
• Optional：Attachment, Side Shifter, Sealed Cab, Mast, etc
• Mast：Duplex Mast (Triplex Mast Optional)
• Color：Customized
• Certification：CE,ISO
• Transport Package：Container
• Specification：4870x2000x2480mm(LXWXH)
• Trademark：Hifoune
• Origin：Cn
• HS Code：8427109000
• Production Capacity：4500sets,Year

ModelUNITFD70TSpecificationsPower Unit DieselOperator Type Driver/seatTransimission Box Type Electronic hydraulic transmissonRated Capacitykg7000Load Centermm600Max.Lifting Heightmm3000Tire Type Pneumatic TyreTire Number 4Rear2Tire Size8.25×15-14PRRear 8.25×15-14PRPerformanceLifting SpeedLoadedmm/s450Unloaded500Lowering Speedmm/s500Unloaded450Travelling Speedkm/h25Unloaded30Max.Gradeability (Loaded)%27Max.Drawbar Pull (Loaded)kg5400Mast Tilting Angle (Fwd/Bwd)deg6/12Free Lifting Heightmm155Turning Radiusmm3370DimensionsOverall Length (with fork)mm4870Overall Widthmm2000Overhead Guard Heightmm2480Fork Size (LxWxT)mm1220x150x65Mast Height (Fork lowered)mm2500Battery (Voltage/Capacity)V/Ah2×12/90Truck Weightkg9200Fuel Tank CapacityL135EngineBrandModel 6BG1S6S-T6102Rated Powerkw/rpm82.3/200067.6/230080.8/250Rated torquen-m/rpm418/1500293/1700354/1650Number Of Cylinder 666Displacement 6.494.995.78





Shipping & Packing

About us
Xiamen Hifoune Machinery Co., Ltd. is located in the Xiangan industrial zone of Xiamen torch high tech Zone. It is dedicated to providing reliable and efficient material handling equipment and solutions for customers. It is a professional company integrating R & D, manufacturing, sales and service. Our main products include a full range of internal combustion counterbalanced forklift trucks, electric counterbalance forklift trucks, and electric warehouse equipment. We not only aim to provide excellent products to customers in our full range of products, but also provide excellent service to customers in all links
