Factory Price Heavy 5 Ton Diesel Forklift Trucks with Side Shift
Xiamen Hifoune Technology Co., Ltd.- Warranty：One Year or 2000hours
- Cab Location：Adjustable
- Type：Diesel Forklift
- Power：Diesel Engine
- Load Capacity：5T - 10T
- Fuel：Diesel
Base Info
- Model NO.：FD50T
- Load center：600mm
- Lift height：>5000mm
- Condition：New
- Engine：Xinchai,Isuzu,Mitsubish
- Weight：7900kg
- Rated Capacity：5000kg
- Fork Size：1220X150X55mm
- Transmission Box Type：Automatic Transmission
- Tire Type：Pneumatic Tire
- Transmission：Hydraulic
- Optional：Attachment, Side Shifter, Sealed Cab, Mast, etc
- Mast：Duplex Mast (Triplex Mast Optional)
- Color：Customized
- Certification：CE,ISO
- Transport Package：Container
- Specification：4715x2000x2480mm(LXWXH)
- Trademark：Hifoune
- Origin：Cn
- HS Code：8427209000
- Production Capacity：4500sets,Year
Description
ModelUNIT FD50T Specifications Power Unit Diesel Operator Type Driver/seat Transimission Box Type Electronic hydraulic transmisson Rated Capacity kg 5000 Load Center mm 600 Max.Lifting Height mm 3000 Tire Type Pneumatic Tyre Tire Number Front 4 Rear 2 Tire Size Front 8.25×15-14PR Rear 8.25×15-14PR Performance Lifting Speed Loaded mm/s 450 Unloaded 500 Lowering Speed Loaded mm/s 500 Unloaded 450 Travelling Speed Loaded km/h 25 Unloaded 30 Max.Gradeability (Loaded) % 33 Max.Drawbar Pull (Loaded) kg 5500 Mast Tilting Angle (Fwd/Bwd) deg 6/12 Free Lifting Height mm 145 Turning Radius mm 3250 Dimensions Overall Length (with fork) mm 4715 Overall Width mm 2000 Overhead Guard Height mm 2480 Fork Size (LxWxT) mm 1220x150x55 Mast Height (Fork lowered) mm 2500 Battery (Voltage/Capacity) V/Ah 2×12/90 Truck Weight kg 7900 Fuel Tank Capacity L 135 Engine Brand ISUZU MITSUBISH CHAOCHAI Model 6BG1 S6S-T 6102 Rated Power kw/rpm 82.3/2000 67.6/2300 80.8/250 Rated torque n-m/rpm 418/1500 293/1700 354/1650 Number Of Cylinder 6 6 6 Displacement 6.49 4.99 5.78
