• Model NO.：FG35T
• Load center：500mm
• Lift height：>5000mm
• Condition：New
• Engine：Nissan
• Weight：4610kg
• Rated Capacity：3500kg
• Fork Size：1220X125X50mm
• Transmission Box Type：Automatic Transmission
• Tire Type：Pneumatic Tire
• Transmission：Hydraulic
• Optional：Attachment,Side Shifter, Sealed Cab, Mast, etc
• Mast：Duplex Mast (Triplex Mast Optional)
• Color：Customized
• Certification：CE,ISO
• Transport Package：Container
• Specification：2760x1240x2130mm(LXWXH)
• Trademark：UNITCM
• Origin：Cn
• HS Code：8427109000
• Production Capacity：4500sets,Year

ModelUNITFG35TSpecificationsPower Unit gasolineOperator Type Driver/seatTransmission Box Type Electronic hydraulic transmissonRated Capacitykg3500Load Centermm500Max. Lifting Heightmm3000Tyre Type Pneumatic TyreTyre Number(Front/Rear) 2/5Tyre Size (Front/Rear) 28×9-15-14PR/6.5-10-11PRPerformanceLifting Speed (Loaded/Unloaded)mm/s500/550Lowering Speed (Loaded/Unloaded)mm/s480/450Travelling Speed (Loaded/Unloaded)km/h19/20Max. Gradeability (Loaded)%21Max. Drawbar Pull (Loaded)n18Mast Tilting Angle (Fwd/Bwd)deg6/12Free Lifting Heightmm150Turning Radiusmm2460DimensionsOverall length (without fork)mm2760Overall Widthmm1240Overhead Guard Heightmm2130Fork Size (LxWxT)mm1220×125×50Mast Height (Fork lowered)mm2140Battery(Voltage/Capacity)V/Ah12/90Truck Weightkg4610Fuel tank capacityL70EngineBrand  NISSANModel K25Rated Powerkw/rpm37.4/2300Rated torquen-m/rpm176.5/1600Number of cylinder 4Displacement 2.49
