3 Tons Cpcd30 Heli Diesel Forklift Price with Side Shifter
Jinan Wego Import and Export Co., Ltd.- After-sales Service：International Standard
- Warranty：1year
- Cab Location：Adjustable
- Type：Diesel Forklift
- Power：Diesel Engine
- Load Capacity：1T - 5T
Base Info
- Model NO.：CPCD30
- Fuel：Diesel
- Load center：500mm
- Lift height：3000~5000mm
- Condition：New
- Can Be Customized：Can Be Equipped with Different Attachment
- Transport Package：Nude by Wax Spray
- Trademark：HELI
- Origin：China
- HS Code：8427209000
- Production Capacity：50000,Year
Description
Product ParametersModel A1:HELI provide 12 months or 2000 working hours warranty as standard,whichever comes first. Q2: What payment terms do you accept? A2: Our standard payment term is 30% in advance and 70% in balance by TT before delivery or againest BL copy. Meanwhile,we also accept the irrevocable L/C at sight. Q3: How long can I get my order finished? A3: 25 work days for chassis forklift, 7 work days for spare parts. Q4: Do you accept small order? A4: Yes. the MOQ is 1 units for most of products. For very small handling equipments,we can check case by case. CPCD30 Power type Diesel Rated capacity kg 3000 Load center mm 500 Lift height mm 4500 Free lift height mm 145 Fork size mm 1220×125×45 Mast tilt angle deg 6/12 Front overhang mm 482
OverallLength to face of forklift mm 2695 Overall width mm 1225 Mast lowerd height mm 2070 Mast extended height mm 4250 Overhead guard height mm 2090 Turning radius mm 2420 Min.right angle aisle width mm 2885
SpeedsDrive speeds km/h 18/19.5 Lifting speeds mm/s 470/520 Lowering speeds mm/s ≤600 Max.grade ability % 15 Total weight kg 4350
TiresFrot 28*9-12PR Rear 6.5-10-10PR Wheeslbase mm 1700
TreadFront mm 1000 Rear mm 970 Hold under mast mm 110
EngineModel Xinchang 490BPG Rated output kw/rpm 37/2650 Rated torque N.m/rpm 148/2000 No.of cylinder 4 Displacement L 2.54 Fuel tank capacity L 52
Q1: How long is the warranty of your products?
