• Model NO.：FDS30
• Load center：500mm
• Lift height：3600mm
• Condition：New
• Color：Customize
• Min. Ground Clearance：160mm
• Wheel Base：2250mm
• Max. Lifting Height：3600mm
• Free Lifting Height：30mm
• Overall Length：4555mm
• Overall Width：2000mm
• Service Weightof Side Forklift：5300kg
• Engine：Yanmar 4tne98
• Transport Package：Container
• Specification：4555*2000*2500 mm
• Trademark：LTMG
• Origin：China
• HS Code：84272090
• Production Capacity：100sets,Year

Rated load capacity (loader center≤0.6m)3000kgMax. lifting height3.6mfree lifting height0.3mMax. lifting speed (full load)≥0.3m/sdriving speedforward20km/hreverse20km/hFork dipping angle up/down5°/3°Min. turning radius4250mmMax. traction force20.678KNGradeablity20%Ground clearance (Bottom of mast)160mmdimensionsLength4555mmWidth (Without the back mirror)2000mmHeightfork down2460mmfork lifting4660mmWheel base2250mmTrack base1600mmPlatform length4555mmPlatform width1200mmFork size(L×W×H)1070×125×45mmMax. base of the forks0.94mBattery(V/Ah)12/80Tire2×28×9-15-12PR(front)
2×28×9-15-12PR(rear)Service weight5300kgTransmissionTypeHydraulicStageFWD/RVS1/1EngineModelYanmar 4TNE98Rated power(kw/r.p.m.)42.1/2300Rated Torque/r.p.m(kw/r.p.m.)187-207/1700
