• Model NO.：HH30Z
• Fuel：Diesel
• Load center：500mm
• Lift height：3000~5000mm
• Condition：New
• Turning Radius：2320mm
• Gradeability：20%
• Weight：3720kg
• Wheelbase：1200mm
• Ground Clearance：152mm
• Transport Package：Nude
• Specification：2680*1225*2120mm
• Trademark：NEWINDU
• Origin：China
• Production Capacity：1000units,Per Year

Detailed PhotosProduct ParametersSpecification1Model HH30Z2Rated capacitykg30003Load centermm5004Lift heightmm30005Fork sizeL×W×Tmm1070×125×456Mast inclinationfront/back(α°/β°)Deg6/12Size7Overall DimensionLength(to fork face)mm26808Overall Widthmm12259Mast lowered heightmm209510Height When Mast Liftingmm418011Safeguard Heightmm212012Turning Radius minmm246013Front Overhangmm49014Treadfront/backmm1000/97015Ground Clearance min(no load/full load) mast/framemm152/132158/13816Wheelbasemm170017Fork Spreadmin/maxmm300/1200Performance18SpeedTravel (Laden)km/h20/18.519Lifting (Laden)mm/s48020Grade abilityLaden%2021Service Weight(include battery )kg440022TireFront 28×9-15-12PR23rear 6.50-10-10PRDiesel Engine24490BPGRated OutputKw/rpm37/265025Rated TorqueN.m/rpm148/180026Displacementcc254027No.of Cylinder 428Bore*Strokemm90*10029Operating Pressure for AttachmentMpa17.5Packaging & Shipping
