Ltmg 500kg 0.5 Ton 0.5 Tonne Self Loading Truck Stacker Self Load Stacker for Lifting 1300mm

Xiamen LTMG Machinery Co., Ltd.
  • After-sales Service：Free Parts Within Warranty
  • Warranty：1 Year,2000 Working Hours
  • Cab Location：Walkie
  • Type：Stacker
  • Power：DC Motor
  • Load Capacity：≤1T

Base Info

  • Model NO.：SERB05Z
  • Fuel：Electric
  • Load center：500mm
  • Lift height：1300mm
  • Condition：New
  • Fork Size：1570*786*1597mm
  • Item：Stacker
  • Max. Lifting Height：1300mm
  • Overall Length：1570mm
  • Battery Capacity：12V,45ah
  • Operating Weight：245kg
  • Min. Lifting Height：85mm
  • Fork Width：155mm
  • Certification：CE ISO
  • Min.Turning Radius：1110
  • Transport Package：Container
  • Specification：1570*786*1597mm
  • Trademark：LTMG
  • Origin：China
  • HS Code：8428109000
  • Production Capacity：1000sets,Year

Description

Main SpecificationPower unitBatteryOperator typeManual Driving,Electrical LiftingRated load500kgOperating weight245kgBattery performance12V/45AHMax. lifting height1300mmLoad center400mmMax. fork width535mmLowered fork height85mmOverall dimension(L*W*H)1570*786*1597mmMin. turning radius1100mmRated powerDC0.8kwLifting speed55mm/sLowering speed70mm/sMastSingle mastLtmg 500kg 0.5 Ton 0.5 Tonne Self Loading Truck Stacker Self Load Stacker for Lifting 1300mm
Ltmg 500kg 0.5 Ton 0.5 Tonne Self Loading Truck Stacker Self Load Stacker for Lifting 1300mmShipping&packging

Ltmg 500kg 0.5 Ton 0.5 Tonne Self Loading Truck Stacker Self Load Stacker for Lifting 1300mm

Our CustomerLtmg 500kg 0.5 Ton 0.5 Tonne Self Loading Truck Stacker Self Load Stacker for Lifting 1300mm

Ltmg 500kg 0.5 Ton 0.5 Tonne Self Loading Truck Stacker Self Load Stacker for Lifting 1300mm
