• Model NO.：CPQYD15
• Lift height：3000~5000mm
• Condition：New
• Color：Customerized
• Lifing Height：3000-6000mm
• Mast：2 Stage Mast,Full Free Triplex Mast
• Fork Length：1070mm
• Engine Option：Chinese Engine, Japanese Engine, Cummins Engine
• Transport Package：Standard Export Package
• Specification：International standard
• Trademark：GP
• Origin：China
• HS Code：8427209000
• Production Capacity：5000 Unit,Year

General  Manufacturer  GP1Model  CPQYD10CPQYD15CPQYD18CPQ10CPQ15CPQ182Rated capacityKg1000150018003Load centermm5004Gearbox change speed type  Hydraulic/Mechanical5Power type  Gasoline / LPG6Tire typeFront/Rear  Pneumatic7WheelsFront/Rear  2*2/2Dimensions8Lift heightmm30009Free lift heightmm16210Fork sizeL*W*Tmm920*122*4011Mast tilt angleFwd/BwdDeg6/1212Overall length (without fork)mm21802235227013Overall widthmm108014Mast height fork loweredmm199515Overall height fork raisedmm404216Overall height (overhead guard)mm207517Turning radius (outside)mm18901960200018Load distance (centerline of front axle to front face of forks)mm42919Minimum Aisle -90deg stack(Add load length and clearance)mm17401780182020Wheel basemm140021TreadFrontmm89022Rearmm92023Min. Under-clearanceBottom of mastmm958524Bottom of framemm105Performance25SpeedTravel Max. With loadKm/h13.526Without loadKm/h14.527LiftingWith loadKm/h45028Without loadKm/h51029LoweringWith loadKm/h45030Without loadKm/h55031Max. Drawbar pullWith/without loadKg1250/8501250/8501100/1000321650/8501650/8501350/100033Max. GradeabilityWith/without load% (fan)2021Weight34Service weightKg23402740294335Weight distributionWith loadFrontKg34103790417036RearKg37045057037Without loadFrontKg10161096117538RearKg156416441765Tyre39TyreSizeFront  6.50-10-10PR40Rear  5.00-8-8PR5.00-8-10PRBrake41BrakeService  Hydraulic-Foot pedal42Parking  Mechanical-Hand leverTransmission43BatteryVoltage / CapacityV/AH12/8044Internal combustion engineModel  MITSUBISHI / Nissan / GQ-4Y45Rated horsepowerKw/rpm31.2/225046Rated torqueN. M/rpm143/160047Number of cylinder  448DisplacementCc2.06549Fuel tank capacityLit3850TransmissionType  Hydraulic/Mechanical51Shift (Fwd/Rvs)  1/1 (2/2)  52Work pressureMPa17.5
