• Model NO.：EPG220
• Lift height：205mm
• Condition：New
• Brake Type：Electromagnetic
• Battery Voltage：24V
• Battery Capacity：300ah
• Controller：Curtis
• Wheel Base：1310mm
• Fork Dimension：50*170*1150
• Service Weight：650kg
• Overall Length：1901mm
• Overall Width：770mm
• Forklift Height：205mm
• Drive Motor(AC)：1.5kw
• Lift Motor(DC)：2.2kw
• Transport Package：Nude Packing
• Trademark：GP
• Origin：China
• HS Code：842720900
• Production Capacity：5000

Basic Info.

Model NO. EPG220 Lift height 205mm Condition New Brake Type Electromagnetic Battery Voltage 24V Battery Capacity 300ah Controller Curtis Wheel Base 1310mm Fork Dimension 50*170*1150 Service Weight 650kg Overall Length 1901mm Overall Width 770mm Forklift Height 205mm Drive Motor(AC) 1.5kw Lift Motor(DC) 2.2kw Transport Package Nude Packing Trademark GP Origin China HS Code 842720900 Production Capacity 5000

Product Description

Features:

1) Electronic power steering system, light and low noise

2) Drive unit floating bodies wigh patent design

3) AC driving system, no carbon brush, maintenance free

4)USA CURTIS controller, German REMA handler, imported waterproof electrical components

5)Electromagnetic braking system

6)Stepless speed control system

7)Strong drive enforce, big greadability, safe and reliable

8)Controller with multiple automatic protection

9)Integrated hydraulic and power control system, easily operation, reliable performance

10)Emergency reversing device/ emergency brake switch

11)Lifting cylinders patented design, floating lonnection

12)Brake effect when handler at highest and lowest position.

13)Long life limit switch on mast
