Snsc New 2.5ton Electric Forklift Truck
Jinan Shine International Trade Co., Ltd.- Cab Location：Adjustable
- Type：Electric Forklift
- Power：AC Motor
- Load Capacity：1T - 5T
- Fuel：Electric
- Load center：500mm
Base Info
- Model NO.：FB25
- Lift height：>5000mm
- Condition：New
- Controller：USA Curtis Controller
- Hydraulic System：Japan Shimadzu Hydraulic System
- Gear：USA Eaton Steering Gear
- Spare Parts：Free Filters and Seals Maintance Parts
- Light：LED Warning Light
- Seat：Lusury Suspension Seat
- Transmission：Automatic Transmission
- Mirror：3 Way Wider Back Mirror
- Color：Yellow, Green, Red
- Transport Package：Container Package
- Specification：2500kg load capacity
- Trademark：SNSC
- Origin：China
- HS Code：84271090
- Production Capacity：8000set,Year
Description
SpecificationsUnit FB25 1 Characteristics Power - battery 2 Capacity kg 2500 3 Center of load mm 500 4 Lifting height mm 3000 5 Free lifting height mm 145 6 Forks L×W×H mm 1070×122×40 7 Mast tilt angle Forward/Backward . 6/12 8 Min.turning radius mm 2090 9 Min. right angle stacking width mm 3760 10 Min. right angle Aisle width mm 2040 11 Min.ground clearance mm 110 12 Overhead guard height mm 2150 13 Height from seat to overhead guard mm 1005 14 Front overhang mm 470 15 Performance Max.traveling speed(loaded) km/h 13 16 Max.lifting speed(loaded/unload) mm/s 270 300 17 Gradeability % 15 18 Dimensions Overall length (without fork) mm 2310 19 Overall width mm 1150 20 Mast extended height(with bracket) mm 4030 21 Mast lowered height mm 1990 22 Chassis Tire Front - 7.00-12-12PR 23 Rear - 18×7-8-14PR 24 Wheelbase mm 1450 25 Tread width Front/Rear mm 960/950 26 Curb weight None-load kg 4050 27 Powertrain Battery Voltage/Capacity V/Ah 48/630 28 Motor Traveling KW 11 29 Lifting KW 14 30 Controller CURTIS 31 Control type 100%AC 32 Working pressure Mpa 17.5
